DALSA CR-GEN0-M6400R3

Description

Technical Specifications:

• Manufacturer: Teledyne DALSA

• Sensor Type: Global shutter CMOS sensor; or full-frame CCD architecture (per some sources)

• Resolution: 6400 × 4800 pixels

• Pixel Size: 7 µm; or 4.8 µm × 4.8 µm

• Frame Rate: Up to 30 fps; up to 60 fps per some sources; up to 150 kHz for line scan applications

• Color Depth: 12-bit

• Light Sensitivity: 0.01 Lux

• Connectivity: USB 3.0, GigE Vision

• Storage: MicroSD card slot

• Power Supply: 5V DC, 1A

• Dimensions: 100 mm × 70 mm × 40 mm

• Operating Temperature: -20°C to +50°C

Functional Features:

• Advanced global shutter CMOS sensor ensures accurate image capture under challenging lighting conditions

• High resolution enables detailed image analysis for intricate inspection tasks

• High frame rate supports real-time monitoring and tracking applications

• MicroSD card slot for onboard data recording without reliance on external storage

• USB 3.0 and GigE Vision connectivity for seamless integration into modern industrial systems

Performance Parameters:

• 6400-pixel monochrome CMOS sensor with 7 µm pixel size enables ultra-fine spatial resolution for detecting microscopic defects in continuous production lines

• Full-frame CCD architecture optimized for high dynamic range, excellent linearity, and low noise performance

Material Composition: Industrial-grade components designed for harsh environment reliability.

Structural Features: Compact form factor (100 mm × 70 mm × 40 mm) for space-efficient integration. Ruggedized design for reliable operation in demanding industrial environments.

Working Principle: The CR-GEN0-M6400R3 captures high-resolution images using either a global shutter CMOS or CCD sensor. The sensor converts light into digital signals, which are transmitted via USB 3.0 or GigE Vision interfaces to host systems for processing. The global shutter design enables simultaneous exposure of all pixels, eliminating motion artifacts in high-speed applications.

Advantages and Highlights:

• Ultra-high resolution: 6400 × 4800 pixels for detailed inspection

• Global shutter CMOS sensor eliminates motion artifacts

• High frame rate capabilities (up to 150 kHz for line scan)

• Flexible storage with onboard MicroSD card slot

• Dual connectivity: USB 3.0 and GigE Vision

• Compact size optimizes space usage in industrial layouts

• Wide operating temperature range: -20°C to +50°C

Applicable Industries:

• Machine Vision

• Industrial Inspection and Quality Control

• Manufacturing Automation

• Scientific Research

• Continuous Production Line Defect Detection

Model Series: Teledyne DALSA Genie Series

Installation Requirements:

• Requires 5V DC, 1A power supply

• USB 3.0 or GigE Vision compatible host system

• Mounting within specified operating temperature range (-20°C to +50°C)

• Ensure adequate cabling for data and power connections

Usage Precautions:

• Operate within specified temperature range: -20°C to +50°C

• Ensure proper lens selection for intended application

• Use appropriate cabling for USB 3.0 or GigE Vision interfaces

• Protect from moisture and extreme environmental conditions beyond specified ratings
