Compact wide-range input industrial power supply developed by Condor, designed for automation cabinet low-power sensor, relay and small control module power supply, DIN rail snap mounting design with full protection circuit, suitable for factory, marine cabinet, chemical plant control system steady DC power output.
Description
Complete Technical Specifications
- Electrical Output & Input
- Rated Output Power: 60 W continuous
- Standard Output Voltage: 24 VDC, adjustable range 22 ~ 26 VDC via trim potentiometer
- Rated Output Current: 2.5 A
- Input Voltage Range: 85 VAC ~ 264 VAC universal AC wide input
- Input Frequency: 47 Hz ~ 63 Hz
- Ripple Noise: ≤ 120 mV peak-to-peak
- Protection Mechanism
- Built-in overvoltage protection, overcurrent protection, short-circuit automatic hiccup recovery protection, over-temperature shutdown protection
- Environmental Index
- Operating Temperature: -10 °C ~ +60 °C, derate power output above +50 °C
- Protection Class: IP20 indoor cabinet use
- Physical Parameters
- DIN rail module size: 110 mm (W) × 125 mm (H) × 40 mm (D)
- Net Weight: 0.41 kg
Core Function Features
- Universal global AC input voltage compatibility, no manual voltage switch adjustment
- Low ripple stable DC output, no interference to precision analog sensor signals
- Automatic recovery after short-circuit fault removal, no manual power cycle required
- Compact narrow-width design saves cabinet installation space
- Built-in input fuse for overload primary circuit protection
Working Principle
AC mains input passes EMI filter circuit to suppress power grid interference, high-frequency switching conversion circuit converts AC to stable isolated 24 VDC low-voltage direct current, secondary side feedback loop dynamically adjusts switching frequency to maintain constant output voltage under variable load current. Multiple hardware protection circuits monitor output voltage, current and internal temperature in real time, trigger power limiting or shutdown when abnormal parameters detected.
Material Composition & Structural Characteristics
- Housing: Black flame retardant ABS plastic DIN rail shell
- Internal Heat Dissipation: Aluminum alloy heat sink for power switching tube cooling
- Wiring Terminals: Screw copper terminals with anti-loosening washers
Installation Requirements
- Snap mount on standard 35 mm DIN rail inside sealed electrical control cabinet
- Maintain minimum 15 mm vertical spacing between adjacent power supplies for heat dissipation
- Input AC wiring use 1.0 mm² above copper wire, output DC circuit use 0.75 mm² shielded twisted wire
Application Scenarios
- Industrial automation PLC cabinet sensor, safety relay power supply
- Marine small local I/O module junction box auxiliary power
- Chemical plant explosion-proof cabinet internal secondary control power
- Packaging machinery conveyor photoelectric sensor centralized power supply
Operation & Usage Precautions
- When ambient temperature exceeds +50 °C, load power must be reduced to maximum 70% rated 60 W
- Never connect AC mains power to output DC terminals, will permanently damage internal switching circuit
- Avoid installing in cabinet areas with oil mist, corrosive gas accumulation for long-term continuous operation
