Bently Nevada C6001011100

Description

Core Measurement Specifications

• Nominal Probe Diameter: 8 mm
• Linear Measuring Gap Range: 0.5 mm – 2.0 mm (20 – 80 mils)
• System Scale Factor: 7.87 V/mm (200 mV/mil)
• Output Signal: DC voltage proportional to gap distance
• Frequency Response Bandwidth: 0 Hz (DC) – 10 kHz (+0/-3 dB)
• Measurement Accuracy: ±0.5% full scale range
• Standard Calibration Target: AISI 4140 carbon steel
• Minimum Measurable Target Diameter: 12.7 mm

Electrical Specifications (System Matching)

• Matching Proximitor Operating Power Supply: -17.5 VDC to -26 VDC
• Maximum Current Consumption: 12 mA
• Output Impedance: 50 Ω
• Supply Voltage Stability: ≤2 mV output drift per 1 V supply voltage change
• Signal Isolation: Full galvanic isolation between probe circuit and monitoring system internal circuits

Mechanical & Structural Specifications (Exclusive for C6001011100)

• Probe active section: Fully unthreaded smooth structure
• Probe body length: Standard short body size
• Integral fixed cable length: Standard factory fixed length
• Connector type: Miniature coaxial ClickLoc™ quick-lock connector
• Probe tip material: High-performance polyphenylene sulfide (PPS)
• Probe housing material: AISI 303 / 304 stainless steel
• Probe outer diameter: 8 mm
• Net weight of complete probe assembly: 0.38 kg

Environmental Specifications

• Probe Operating Temperature: -52 °C to +177 °C standard temperature grade
• Probe Storage Temperature: -55 °C to +200 °C
• Humidity Resistance: 100% condensing environment, non-submerged operation
• Protection Rating: IP67
• Anti-vibration Performance: 10–2000 Hz, 10 g continuous acceleration resistance
• Anti-interference Performance: Fully complies with industrial EMC electromagnetic compatibility standards

Certifications & Compliance

• Fully compliant with API 670 Machinery Protection Standard
• CE industrial safety certification
• CSA certification
• RoHS lead-free compliant
• Original factory OEM customized qualified certification

Core Functional Features

1. 8 mm High-Precision Eddy Current Non-Contact Measurement

   No physical contact with rotating shaft targets, completely eliminates mechanical wear, maintains long-term stable measurement accuracy and service life. It realizes high-precision detection of micro gap changes and micro vibration displacement.
2. OEM Custom Exclusive Part Number Design

   C6001011100 is official Bently Nevada customized OEM part number, fully equivalent to standard 330103 series probes in performance, structure and compatibility, dedicated for OEM equipment matching and project spare parts supply.
3. Fully Unthreaded Probe Body Structure

   Smooth unthreaded probe shaft, easy insertion into mounting holes, suitable for interference fit, sleeve mounting and OEM customized installation methods.
4. Dual Integrated Measurement Modes

   Supports both static shaft radial/axial position monitoring (DC gap voltage) and dynamic radial vibration monitoring (AC vibration signal), meeting position protection and vibration fault diagnosis requirements simultaneously.
5. ClickLoc Miniature Coaxial Quick Connector

   Fast plug-and-play connection with extension cables or proximitors, reliable contact, anti-loosening structure, greatly improves on-site installation and maintenance efficiency.
6. Standard Wide Temperature Adaptability

   Stable operation from -52 °C to +177 °C, adapts to conventional temperature environments of power plant and petrochemical rotating machinery sites.
7. Full System Interchangeability

   100% interchangeable with standard 3300 XL probes, extension cables and proximitors; no parameter recalibration required after replacement.
8. High-Frequency Response Performance

   0 Hz to 10 kHz bandwidth accurately captures high-frequency vibration faults, realizes early warning of shaft imbalance, misalignment, oil film instability and other mechanical faults.
9. API 670 Standard Compliance

   Meets international rotating machinery protection specifications, supports formal project acceptance and OEM original factory matching applications.
10. High-Strength Stainless Steel Structure

    Corrosion-resistant, oil-resistant and dust-resistant housing, adapts to harsh industrial sites with oil mist, dust and corrosive gas.

Main Application Scenarios

• Power plant steam turbines, gas turbines and generator units OEM matching monitoring
• Petrochemical centrifugal compressors and process compressors OEM spare parts
• Industrial oil pumps, water pumps and high-speed centrifugal pumps customized installation
• Large industrial fans, blowers and induced draft fans OEM configuration monitoring
• High-voltage high-speed motors and motor bearing systems customized probes
• Offshore oil & gas platform rotating production equipment OEM matching
• Chemical processing rotating machinery customized monitoring solutions
• Machinery predictive maintenance and OEM equipment health management systems
• All industrial occasions requiring API 670 standard shaft vibration protection and OEM customized probe supply

Part Number Definition

• C6001011100: Bently Nevada official OEM customized part number
• Fully equivalent performance & structure to standard 3300 XL 8 mm unthreaded ClickLoc proximity probe
• Dedicated for OEM equipment matching, project spare parts and customized supply scenarios
