Bently Nevada 330104-00-04-10-02-00

Basic Identification Parameters

• Brand: Bently Nevada (Baker Hughes Group)
• Exact Model: 330104-00-04-10-02-00
• Product Series: 3300 XL Series
• Product Category: 11 mm Integrated Eddy Current Proximity Probe (Built-in Cable Type)
• Origin: United States
• Standard Warranty: 12 months original factory warranty
• Matching System: 3300 XL Proximitor Signal Conditioner, 3300/3500 Machinery Protection System
• Probe Diameter: 11 mm
• Mounting Thread: M14×1.5 metric thread
• Probe Tip Material: High-temperature resistant PPS engineering plastic
• Probe Body Material: AISI 304 Stainless Steel
• Cable Type: FEP high-temperature resistant shielded coaxial cable
• Built-in Cable Length: 4 meters
• Connector Type: Standard ClickLoc™ miniature gold-plated coaxial locking connector

Measurement & Electrical Specifications

• Measurement Principle: Non-contact Eddy Current Induction Technology
• Effective Linear Measuring Range: 0–2.5 mm
• Optimal Operating Working Gap: 1.5 mm
• System Sensitivity (ISF): 7.87 V/mm (200 mV/mil)
• Power Supply: -18 VDC to -24 VDC negative DC power (supplied by proximitor)
• Frequency Response Range: DC (0 Hz) – 10 kHz flat amplitude response
• Full-Scale Measurement Accuracy: ±0.5% FS
• Static Gap Resolution: 0.1 μm
• Temperature Drift Coefficient: ≤0.01% FS/°C
• Dynamic Response Time: ≤5 ms
• Output Signal: DC static gap voltage + AC dynamic vibration composite signal
• Output Impedance: 50 Ω standard impedance
• Minimum Target Conductive Area: ≥25 mm diameter circular surface

Mechanical & Environmental Specifications

• Overall Probe Active Length: 40 mm
• Minimum Cable Bend Radius: 25.4 mm
• Cable Pull Resistance: ≥330 N
• Environmental Protection Grade: IP67 dustproof and waterproof
• Probe Operating Temperature Range: -40°C to +85°C continuous operation
• Probe Tip Maximum Short-Term Temperature Resistance: +177°C
• Cable Operating Temperature Range: -40°C to +105°C
• Storage Temperature Range: -55°C to +125°C
• Operating Humidity: 0–95% RH, non-condensing
• Anti-vibration Performance: 15 g RMS, 10–2000 Hz
• Anti-shock Performance: 100 g, 11 ms duration
• Electromagnetic Compatibility: Compliant with EN 61000-6-2, EN 61000-6-3 industrial EMC standards

Certifications & Compliance

• Industry Standard Compliance: API 670 4th Edition Machinery Protection Standard
• Safety Certifications: CE, ATEX, IECEx Intrinsically Safe Certified
• Full system compatibility with Bently Nevada 3300 and 3500 protection systems

Core Functional Features

1. 11mm Large Diameter High-Stability Measurement

   11mm probe diameter provides larger detection area, higher signal stability and lower noise than 8mm probes, more suitable for large-diameter heavy rotor shaft measurement.

2. Integrated Built-in Fixed Cable Design

   Integrated probe and cable integrated molding structure, eliminates intermediate connector signal loss and fault points, improves overall system reliability.

3. Simultaneous Static & Dynamic Signal Detection

   Independently outputs DC static axial position gap signal and AC dynamic radial vibration signal, realizes synchronous monitoring of shaft thrust displacement and rotor vibration status.

4. Ultra-Low Temperature Drift High Stability

   Professional temperature compensation design, extremely low temperature drift, maintains consistent accurate measurement data under large ambient temperature changes.

5. Patented ClickLoc™ Locking Connector

   Gold-plated positive locking coaxial connector, tool-free quick plug/unplug, low signal attenuation, stable connection under strong vibration conditions.

6. High Robust Harsh Environment Adaptability

   Full stainless steel body, PPS high-temperature tip, FEP shielded cable, IP67 protection, resistant to oil mist, corrosion, dust and high temperature.

7. Complete API 670 Safety Compliance

   Fully meets international machinery protection safety standards, applicable to safety-critical interlock protection occasions.

8. Full System Seamless Compatibility

   Direct matching with original 3300 XL proximitors, 3300/3500 monitoring racks, no additional calibration required after installation.

Main Application Scenarios

1. Thermal Power Generation Industry

   Shaft radial vibration, axial thrust position and differential expansion monitoring for large steam turbines, gas turbines, generator rotors and bearing pedestal systems.

2. Oil & Natural Gas Industry

   Non-contact shaft position and vibration monitoring for offshore platform centrifugal compressors, gas turbines, oil pipeline main pump units and gas transmission station rotating equipment.

3. Petrochemical & Chemical Industry

   Health monitoring of large centrifugal compressors, reciprocating compressors, heavy-duty centrifugal pumps, fan main shafts and reaction kettle drive rotating machinery.

4. Heavy Metallurgy & Manufacturing Industry

   Shaft vibration and position monitoring for large rolling mill main shafts, high-speed heavy centrifuges, large industrial motors and generator units.

5. Water Conservancy & Municipal Industry

   Rotor vibration and axial displacement monitoring for large circulating water pumps, drainage pump stations and hydraulic turbine units.

6. Equipment Maintenance & Retrofit Projects

   Original spare replacement and upgrade of legacy 3300 series 11mm proximity probes, realizing seamless continuation of original machinery protection monitoring functions.
