BECKHOFF CP7002-0001-0010

Description

Technical Specifications:

• Product Type: Industrial Control Panel / Integrated Touchscreen Device

• Processor: Intel Core i7-8700T Processor

• Memory: 16 GB DDR4 RAM

• Storage: 256 GB SSD

• Operating System: Windows 10 IoT Enterprise

• Interfaces: 2 × Gbit Ethernet, 4 × USB 3.0, 2 × DisplayPort, 1 × DVI-I, 1 × Audio Line-out, 1 × Mic-in

• Serial Ports: 2 × RS232/422/485

• Display Resolution: 1024 × 768

• Power Supply: 24 VDC (nominal)

• Operating Temperature: 0°C to 50°C

• Relative Humidity: 10% to 90%

• Vibration Resistance: 1 g (5 to 500 Hz)

• Shock Resistance: 15 g (11 ms)

• EMC Compliance: CE, FCC Class A

Note: Alternative specifications list Intel Core i7-6600U 2.6 GHz (up to 3.4 GHz with Turbo Boost), up to 16 GB DDR4 SDRAM, up to 512 GB SSD, Intel HD Graphics 520, and support for Windows 10 IoT Enterprise or Linux, indicating configuration variability.

Functional Features:

• High-Performance Computing: Intel Core i7 processor delivers powerful computing capability

• Ample Memory: 16 GB DDR4 RAM for demanding applications

• Fast Storage: 256 GB SSD for rapid data access

• Comprehensive Connectivity: 2 × Gbit Ethernet, 4 × USB 3.0, DisplayPort, DVI-I

• Fanless Design: Rugged design for harsh industrial environments

• Wide Compatibility: Compatible with multiple industrial automation devices and systems

• Easy Programming and Debugging: Supports multiple programming languages and debugging tools

• Good Expandability: Multiple expansion options for system upgrades and functional expansion

Performance Parameters:

• Processor Performance: Intel Core i7-8700T or i7-6600U with Turbo Boost up to 3.4 GHz

• Memory Capacity: 16 GB DDR4 RAM

• Storage Capacity: 256 GB to 512 GB SSD

• Network Speed: 2 × 10/100/1000 Mbps Ethernet

• Environmental Tolerance: 0°C to 50°C operating temperature, 1 g vibration resistance, 15 g shock resistance

Material Composition:
Rugged industrial-grade construction with fanless design for reliability in harsh environments. The control panel is built to withstand vibration (1 g, 5-500 Hz) and shock (15 g, 11 ms).

Structural Characteristics:

• Form Factor: Compact industrial control panel with integrated touchscreen

• Cooling: Fanless design for enhanced reliability

• Mounting: Designed for industrial panel installation

• Connectivity: Comprehensive interface ports on the panel for easy access

Working Principle:
The CP7002-0001-0010 functions as an industrial control panel that provides human-machine interface and control capabilities for automation systems. The Intel Core i7 processor runs Windows 10 IoT Enterprise or Linux, executing control applications and providing visualization. The panel connects to network communication modules (switches) or other network devices, transmitting signals to PLCs to complete control tasks. The integrated touchscreen enables operator interaction, while multiple communication interfaces facilitate integration with various industrial automation设备和 systems.

Advantages and Strengths:

• High-performance Intel Core i7 processor

• 16 GB DDR4 RAM and SSD storage for demanding applications

• Fanless rugged design for harsh industrial environments

• Comprehensive connectivity with 2 × Gbit Ethernet and multiple USB ports

• Wide compatibility with industrial automation devices

• Supports multiple programming languages and debugging tools

• Good expandability for system upgrades

Applicable Industries:

• Industrial automation

• Manufacturing

• Machine control

• Data acquisition and monitoring

Model Series:
Part of Beckhoff’s CP7000 series of industrial control panels.

Installation Requirements:

• Power Supply: 24 VDC (nominal)

• Environmental: Operating temperature 0°C to 50°C; humidity 10% to 90%

• Mounting: Industrial panel installation

• EMC: CE and FCC Class A compliance

Usage Precautions:

• Environmental: Ensure operating temperature within 0°C to 50°C range

• Vibration/Shock: Protect from excessive vibration and shock beyond 1 g and 15 g limits

• Power Supply: Maintain stable 24 VDC power

• Programming: Utilize supported programming languages and debugging tools for efficient development
