Digital Inputs: 8 channels, 24 VDC, PNP/NPN compatible
-
Analog Inputs: 4 channels, 0–10 V / 4–20 mA, 16-bit resolution, 1 kHz sampling rate
-
Digital Outputs: 6 channels, transistor output, 24 VDC / 2 A (some sources cite 16 DI / 16 DO configurable)
-
Analog Outputs: 2 channels, 4–20 mA, 14-bit resolution
-
Communication Protocols: RS-485 (Modbus RTU, 115200 bps), EtherCAT (≤ 1 ms cycle time); family variants also report Modbus TCP, CAN bus, PROFINET
-
Processing: Onboard logic engine (16 MHz master clock in extended variants) supporting custom algorithms (PID, fuzzy logic)
-
Physical Dimensions (W×H×D): 110 mm × 150 mm × 50 mm
-
Weight: ~0.7 kg
-
Protection Rating: IP20 (must be installed inside control cabinet / interface box)
-
Operating Temperature: -10 °C to +55 °C (extended variants rated -40 °C to +85 °C)
-
Storage Temperature: -40 °C to +85 °C
-
Compatible Equipment: ASYST M-1000 wafer handling robots, Teradyne chip testers, Fuji pick-and-place machines
-
Core Functions: Signal type conversion, cross-device data exchange, communication fault diagnostics, cleanroom-environment adaptation
-
Application Fields:
-
Semiconductor manufacturing (wafer transport, etch, deposition)
-
3C electronics manufacturing
-
Chip testing & packaging lines
-
Industrial automation (robot arms, CNC machine closed-loop control)
-
Installation: DIN-rail or panel mount inside sealed control enclosure; ensure 24 VDC supply stability within ±10 %; protect from particulate contamination (IP20)
-
Usage Notes: For EtherCAT deployment, confirm network topology & master configuration before power-on; RS-485 bus must be properly terminated with 120 Ω at both ends.
