Description
Technical Specifications
- Detection Spectrum: Ultraviolet (UV) Spectrum
- Detection Distance: Max 2100 mm
- Operating Voltage: 18 ~ 32 V DC
- Response Time: ≤ 100 ms
- Operating Temperature (Sensor Head): -40 °C ~ +125 °C
- Operating Temperature (Circuit Part): -20 °C ~ +70 °C
- Output Signal: Standard Switch Signal
- Protection Class: IP65
Structural Features
Integrated split structure: high temperature resistant probe head + signal processing unit; stainless steel probe shell, sealed waterproof and dustproof structure, threaded installation interface, internal high-sensitivity UV detection tube.
Functional Characteristics
Real-time monitor flame state of combustion equipment, identify flame existence or extinguishment, output switch signal to interlock control system, realize flame failure protection.
Working Principle
The internal UV sensing tube receives ultraviolet ray generated by fuel combustion, converts optical signal into electrical signal; after signal amplification and processing, judge flame state and output corresponding control signal to external control system.
Material Composition
Probe shell: 304 stainless steel; Internal sensing element: UV phototube; Optical lens: High temperature resistant quartz glass; Circuit part: Industrial PCB, semiconductor components; Sealing part: Fluorine rubber high temperature resistant sealing ring.
Advantages & Highlights
High flame detection sensitivity, strong anti-interference to visible light and infrared light, high temperature resistance of probe, fast response, stable operation, waterproof and dustproof, reliable flame protection performance.
Applicable Industries
Boiler combustion system, industrial furnace, gas burner, oil burner, thermal power equipment, petrochemical combustion equipment.
Installation Requirements
- Install the probe at the position facing the flame center, ensure unobstructed optical path.
- Use matching thread for fixed installation, keep sealing integrity.
- Signal wiring uses shielded cable, separate from power cable to avoid interference.
- The probe head shall not be in direct contact with flame and high temperature flue gas for a long time.
Usage Notes
- Keep the quartz lens clean regularly, remove dust and carbon deposition.
- Do not scratch or collide the lens to avoid affecting detection effect.
- Check wiring tightness and shielding layer integrity periodically.
- Replace the UV tube regularly according to service life requirements.
