Product Short Description
Product Name: Allied Telesyn AT-MR126F, Fast Ethernet Media Converter (10/100TX to 100FX)
Product Introduction: The AT-MR126F is a high-performance media converter designed to extend network distance by converting Fast Ethernet data between twisted pair cabling and fiber-optic cabling. It is ideal for extending network connections over longer distances.
Description
Technical Specifications:
-
Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
-
Ports: 1 × RJ-45 (10/100Base-TX), 1 × SC (100Base-FX)
-
Data Transfer Rate: 100 Mbps
-
Supported Cabling: 10Base-T, 100Base-TX, 100Base-FX
-
Multimode Fiber Distance: Up to 2 km
-
LED Indicators: Power, Link/Activity, Full-Duplex/Collision
-
Power Adapter: External 5 V DC, 1 A
-
Dimensions: 95 × 70 × 26 mm (W×D×H)
-
Weight: 0.14 kg
-
Certifications: FCC Class A, CE Mark Class A, VCCI Class A
Functional Features:
-
Converts 10/100TX twisted pair to 100FX fiber media
-
LED indicators for quick network status identification
-
Compact design for easy deployment
-
Full-duplex flow control and half-duplex backpressure flow control
Application Scenarios: Extending network connections over longer distances; connecting network segments via fiber optic cabling; integrating multimode fiber infrastructure into Fast Ethernet networks.
Environmental Specifications:
-
Operating Temperature: 0 °C to 40 °C
-
Storage Temperature: -10 °C to 70 °C
-
Humidity: 10% to 90% RH (non-condensing)
Installation Requirements: Connect the RJ-45 port to the twisted pair network and the SC fiber port to the multimode fiber link. Attach the external 5 V DC power adapter. Use appropriate multimode fiber (62.5/125 µm or 50/125 µm) for distances up to 2 km.
Usage Precautions: Ensure proper fiber optic cable type matching (multimode for 2 km max). Verify LED indicators show correct link and activity status after installation.
