Product Short Description
Product Name: Industrial-grade multi-channel analog signal acquisition module.
Product Overview: This module is engineered for automation control systems and industrial field data acquisition. It efficiently processes sensor signals and converts them into digital signals for transmission, and is widely used in manufacturing, energy management, and environmental monitoring.
Description
Technical Specifications:
-
Channels: 12 differential input channels
-
ADC Resolution: 16-bit (±0.003% FSR)
-
Sampling Bandwidth: DC–50 kHz (-3 dB)
-
Input Impedance: >1 MΩ per channel
-
Input Modes: ±10 V voltage input and 4–20 mA current input
-
Channel-to-System Isolation: 2500 Vrms
-
Communication Interface: RS-485 / Modbus RTU
-
Operating Temperature: -40 °C to +85 °C
-
Enclosure Protection: IP67 metal housing
Key Features:
-
Military-grade circuit design with 12-channel synchronous sampling architecture
-
Single-channel sampling rate up to 100 kHz
-
Advanced anti-interference filtering technology
-
Seamless integration with PLC systems and Industrial IoT (IIoT) scenarios
Application Scenarios:
-
Generator set vibration monitoring systems
-
CNC machine tool condition monitoring
-
Smart grid power quality analysis
-
Oil pipeline pressure monitoring
-
Environmental monitoring station data acquisition
-
Industrial robot sensor integration
