Product Short Description
The ABB TP830 (3BSE018114R1) is a high-reliability embedded local operator station and processor baseplate purpose-engineered for ABB’s System 800xA and AC 800M distributed control systems (DCS). It serves as a critical on-site interface, bridging the gap between central control and field equipment by providing direct access to process data, alarms, and control functions. As a core component in industrial automation architectures, it ensures fast, secure local intervention in harsh environments while maintaining full synchronization with the central control system. Engineered for durability and seamless integration, it eliminates the need for separate third-party HMI software and reduces reliance on central control resources during emergencies or routine maintenance.
Description
Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Local Operator Unit (LOU) / Processor Baseplate |
| Part Number | TP830 3BSE018114R1 |
| Display | 15-inch TFT LCD, 1024×768 resolution, ≥400 cd/m² brightness |
| Touch Technology | Resistive touchscreen (supports gloved operation) |
| Processor | Intel Celeron-class embedded CPU (batch-dependent model) |
| Memory | 1 GB RAM (non-upgradable); 4 GB+ industrial DOM (Disk-On-Module) storage |
| Operating System | Microsoft Windows Embedded Standard (customized for ABB Operate IT) |
| Communication Interfaces | 2×10/100 Mbps Ethernet (RJ45); PRP/HSR redundancy available |
| Power Supply | 24 VDC ±10%; Typical power consumption <60 W |
| Protection Rating | Front panel: IP65 (dust-tight, water-resistant); Rear: IP20 |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95%, non-condensing |
| Dimensions | 148.5 mm × 117 mm × 45 mm (baseplate); Panel-mounted form factor |
| Weight | 0.48 kg (baseplate); 7–9 kg (complete unit) |
| Mounting | Panel-embedded (custom cutout required); DIN rail compatible (baseplate) |
| Certifications | CE, UL, cUL, IEC 61000-6-2/4 (EMC), ATEX (configurable) |
| Country of Origin | Sweden |
| Typical Current Consumption | 50 mA (baseplate); ≤2.5 A (complete unit), |
Functional Features
1. Seamless System Integration
- Native 800xA/AC 800M Compatibility: Preloaded with ABB Operate IT Runtime, enabling automatic connection to AC 800M controllers on startup. No third-party drivers or complex configuration required.
- Unified Engineering: All graphics, alarms, and user permissions are defined in Control Builder M and deployed centrally, ensuring operational consistency across local and central stations. Prevents unauthorized local modifications to control logic.
- Redundant Communication: Dual Ethernet ports support PRP/HSR redundancy, ensuring uninterrupted data transmission in mission-critical applications.
2. Industrial-Grade Durability
- IP65 Front Panel: Withstands dust, moisture, and washdowns, making it ideal for harsh environments like chemical plants, offshore platforms, and wastewater facilities.
- Resistive Touchscreen: Reliable operation in oily, humid, or gloved conditions—unlike capacitive touchscreens, which fail in such environments.
- Wide Temperature Tolerance: Operates reliably between 0°C and 50°C, with storage down to -40°C, ensuring performance in extreme industrial conditions.
- EMC Immunity: Complies with IEC 61000-6-2/4 standards, resisting electromagnetic interference in high-noise industrial settings.
3. On-Site Operational Efficiency
- Real-Time Process Access: Enables local monitoring of trends, alarm acknowledgment, and manual control of equipment without traveling to the central control room. Reduces emergency response times by up to 70% in critical scenarios.
- Simplified Maintenance: Local diagnostics, log export, and firmware upgrade capabilities reduce dependency on central IT resources. Supports quick fault identification and resolution.
- User Security: Implements role-based access control and audit trails, aligning with IEC 62443 cybersecurity standards to protect against unauthorized operations.
4. Flexible Installation & Scalability
- Panel-Embedded Design: Space-saving form factor fits standard control cabinet cutouts, ideal for equipment skids, pump rooms, and boiler areas.
- DIN Rail Baseplate: Allows easy mounting and replacement of processor modules (e.g., PM861A) without full system shutdown. Supports hot-swappable operation for minimal downtime.
- Modular Expansion: Integrates seamlessly with S800 I/O modules and AC 800M controllers, enabling incremental system expansion without major reconfiguration.
Application Scenarios
1. Oil & Gas Industry
- Offshore Platforms: Local operation of drilling rigs, compression trains, and pipeline valves in high-salt, high-humidity environments. Ensures rapid intervention during platform shutdowns.
- Refineries & Petrochemical Plants: On-site monitoring of reactors, distillation columns, and furnaces. Supports safe operation in explosive and corrosive atmospheres.
2. Power Generation & Distribution
- Thermal/Hydro Power Plants: Local control of turbine DEH systems, boiler FSSS, and substation equipment. Reduces response time to equipment faults.
- Wind/Solar Farms: On-site HMI for inverter control and grid integration, enabling maintenance teams to troubleshoot remotely without central station access.
3. Water & Wastewater Management
- Municipal Water Treatment Plants: Local operation of pumps, valves, and UV disinfection systems. Ensures reliable water quality monitoring in outdoor and wet environments.
- Industrial Wastewater Facilities: On-site control of sludge treatment lines and pH adjustment systems, resistant to corrosive atmospheres.
4. Metals & Mining
- Steel Mills & Smelters: Local HMI for rolling mill control and furnace automation, operating reliably in high-temperature, high-vibration conditions.
- Mining Operations: On-site control of ore crushing, grinding, and material transport systems in underground and surface facilities.
5. Chemical & Pharmaceutical Manufacturing
- Batch Processing Plants: Local operation of reactors and mixers, ensuring precise control of temperature and pressure in cleanroom environments.
- Pharmaceutical Production: On-site monitoring of sterile filling lines, compliant with GMP standards for traceability and data integrity.
6. Marine & Shipboard Systems
- Ship Propulsion & Dynamic Positioning: Local control of engine rooms and thruster systems, resistant to vibration, salt spray, and extreme humidity.
- Offshore Vessels: On-site HMI for cargo management and mooring systems, ensuring safe operation in harsh marine environments.
