ABB PP826 Panel 800 Operator Interface (HMI) Panel

Description

Technical Specifications

• Product Type: Operator Interface Panel (HMI)
• Display:
  • Screen Size: 5.7-inch CSTN color LCD
  • Resolution: 320 × 280 pixels
  • Color Depth: 64K colors
  • Visibility: Wide viewing angle, readable in high-ambient light conditions
• User Input:
  • Keypad: 20 programmable function keys with membrane keys
  • Feedback: LED indicators for key status and operational feedback
• Power Supply:
  • Input Voltage: 24 V DC
  • Power Consumption: 10 W maximum
• Communication Interfaces:
  • Protocols: CAN, Profibus DP, Modbus RTU
  • Connectivity: Built-in ports for direct connection to controllers and field devices
• Physical Dimensions (W × H × D):
  • Front Panel: 144 mm × 96 mm
  • Total Depth: 35 mm (behind panel)
• Mounting: Front-panel flush mounting
• Environmental Ratings:
  • Front Protection: IP65 (dust-tight, water-resistant)
  • Rear Protection: IP20
  • Operating Temperature: -20°C to +60°C
  • Storage Temperature: -40°C to +70°C
  • Relative Humidity: 10 – 95% non-condensing
  • Corrosion Resistance: G3 industrial environment rating
• Construction:
  • Front Bezel: Die-cast aluminum with powder coating
  • Sealing: Rubber gasket for front-panel environmental protection
• Certifications: CE, UL, cUL, ATEX, DNV-GL, ABS, LR
• Programming: Configurable via ABB Panel Builder 800 software
• Languages: Supports multiple language character sets for global deployment

Key Features

• Robust Industrial Construction:
  • IP65 front-rated design seals out dust, moisture, and chemical splashes for harsh environments.
  • Die-cast aluminum front bezel provides mechanical durability against impact and vibration.
  • Extended temperature operation suits extreme industrial conditions from freezing to high-heat zones.
  • G3 corrosion resistance ensures stable performance in polluted or chemical atmospheres.
• Clear & Functional Display:
  • 5.7-inch color CSTN screen delivers sharp, high-contrast process visualization.
  • Wide viewing angles ensure readability from various operator positions.
  • Backlit display maintains visibility in low-light or high-glare industrial settings.
  • Supports dynamic graphics, trend graphs, alarm lists, and system diagnostics.
• Intuitive & Programmable Operation:
  • 20 customisable function keys enable quick access to frequent commands and screens.
  • LED key indicators provide clear visual feedback for active functions and status.
  • Tactile membrane keys ensure reliable operation even with gloved hands.
  • Fully programmable key assignments adapt to specific process or machine requirements.
• Seamless System Integration:
  • Native communication with ABB AC 800M controllers and System 800xA DCS.
  • Multi-protocol support (Profibus DP, Modbus RTU, CAN) for third-party device connectivity.
  • Real-time data exchange with control systems for accurate process mirroring.
  • Plug-and-play compatibility reduces engineering and integration time.
• Advanced Software & Security:
  • Panel Builder 800 software enables drag-and-drop HMI application development.
  • Pre-built industrial symbol libraries and template screens accelerate project deployment.
  • Multi-level user access security prevents unauthorised parameter changes or operation.
  • Alarm and event logging supports regulatory compliance and troubleshooting.
• Reliable & Maintenance-Free:
  • Fan-less, solid-state design eliminates moving parts for maximum reliability.
  • Conformal coating option for enhanced protection against humidity and pollutants.
  • Hot-swappable capability allows replacement without full system shutdown.
  • Comprehensive self-diagnostics monitor hardware health and communication status.

Application Scenarios

• Process Automation (Oil & Gas, Chemical, Pharmaceutical):
  • Local control and monitoring for reactors, distillation columns, and purification systems.
  • Operator interface for batch processes, recipe management, and sequence control.
  • Alarm acknowledgement and parameter adjustment in hazardous area classified zones.
• Power Generation & Distribution:
  • Turbine, boiler, and generator auxiliary system control in power plants.
  • Switchgear and substation equipment monitoring and operation.
  • Grid interconnection and load balancing control interfaces.
• Metals & Mining:
  • Furnace, rolling mill, and continuous casting machine local operation.
  • Conveyor, crushing, and material handling system control.
  • High-temperature and high-vibration industrial environment operation.
• Water & Wastewater Treatment:
  • Pump, valve, and filter station control in water treatment plants.
  • Flow, level, and pressure parameter adjustment and monitoring.
  • SCADA system local operator interface for remote pumping stations.
• Food & Beverage Manufacturing:
  • Packaging, filling, and mixing machine control.
  • Hygienic zone process interface with wash-down front-panel capability.
  • Batch control and production monitoring for food processing lines.
• Manufacturing & Machinery:
  • Machine tool, assembly line, and robotic workstation local HMI control.
  • Packaging and printing equipment operation and parameter setting.
  • Material handling and warehouse automation system interface.
• Marine & Offshore:
  • Shipboard engine room and propulsion system monitoring.
  • Offshore platform process and utility system control.
  • Marine-certified operation for vessel and offshore installation automation.
