Description
Technical Specifications:
-
Manufacturer: ABB
-
Series: S800A
-
Supply Voltage: 24 VDC
-
Power Consumption: 2 W
-
Total I/O Points: 16
-
Analog Inputs: 8 channels (0–10 V, 4–20 mA)
-
Analog Outputs: 4 channels (0–10 V, 4–20 mA)
-
Digital Inputs: 4 channels
-
Digital Outputs: 4 channels
-
Response Time: Analog I/O < 10 ms; Digital I/O < 1 ms
-
Analog Accuracy: 0.1% of full scale
-
Mounting: DIN rail mounting
-
Protection Rating: IP67
-
Dimensions: 90 × 35 × 25 mm
-
Weight: 0.1 kg
Functional Features:
-
Universal I/O support (analog in/out, digital in/out)
-
High precision (0.1% FS analog accuracy)
-
High reliability with strong anti-interference capability
-
Clear wiring diagram and easy-to-use documentation
Application Scenarios: Industrial automation control systems, field signal acquisition and control output.
Installation Requirements: DIN rail mounting.
Usage Notes: Ensure correct wiring per the provided wiring diagram.
