Product Short Description
Product Name: DeviceNet Configuration Terminal (HIM – Human Interface Module)
Product Overview:
The Bulletin 193-DNCT is a handheld/panel DeviceNet Human Interface Module that allows qualified personnel to configure, monitor, and troubleshoot DeviceNet nodes directly on the network without a PC. It communicates with PLCs, drives, and DeviceNet-enabled devices.
Description
Technical Specifications:
-
Manufacturer: Allen-Bradley / Rockwell Automation
-
Catalogue Number: 193-DNCT
-
Network: DeviceNet (ODVA)
-
Operating Temperature: 0–50 °C (32–122 °F)
-
Storage Temperature: -40–85 °C
-
Humidity: 5–95 % non-condensing
-
Shock (operating): 30 g
-
Vibration (operating): 2.5 g @ 5 Hz–2 kHz
-
Front-panel dimensions: 70 mm width × 15.5 mm depth
-
Weight: 85 g
-
Agency Approvals: C22.2 No. 14, EN61000-6-2:2005, EN61000-6-4:2001, RoHS
Key Features:
-
Direct node addressing (0–63) and parameter read/write on any DeviceNet device
-
Auto-display mode for automatic monitoring of 1–4 parameters from 1–4 devices at power-up
-
LCD with adjustable contrast (0–100 %)
-
Copy/paste support across parameter screens, CIA editor, and graph setup
-
Programmable function keys (Run Forward, Run Reverse, Output A/B toggle, Reset)
-
Onboard help system for qualified personnel
Application Scenarios:
Commissioning and maintenance of DeviceNet networks in factory automation, drive configuration (e.g., PowerFlex), motor overload relays, and smart I/O commissioning.
Installation & Usage Notes:
-
Read the entire user manual (Rockwell Publication 193-UM009) before installation.
-
Only qualified personnel with DeviceNet knowledge may operate the terminal.
-
Follow the DeviceNet Media Design and Installation Guide (DNET-UM072) for network planning.
-
Observe all safety guidelines in SGI-1.1 (Safety Guidelines for the Application, Installation and Maintenance of Solid-State Control).
-
The terminal must be powered via the DeviceNet bus or a compliant 193-CB1/193-CM1/193-DNCT-BZ1 connection.
