Product Short Description
Product Overview & Brief Introduction
This model is medium-power variant of S300 NA servo drive series, single-phase 110V~230V AC mains input design, reserved multiple optional industrial fieldbus expansion card slots including CANopen, SynqNet, EtherCAT and Profinet RT. The NA suffix retains incremental-only encoder hardware configuration without absolute encoder decoding circuit, suitable for medium torque AKM series servo motors applied in packaging, printing and textile automation equipment, inheriting all upgraded high-bandwidth control, 300 programmable positioning tasks and expanded isolated digital I/O functions of S300 platform.
Description
Unified S300 Series Base Parameters
All base control architecture, NA-version encoder hardware restriction, motion reference input modes, onboard digital I/O quantity, programmable motion task storage capacity, compliance certifications and environmental operating parameters are fully consistent with S30301-NA, only power supply input type and current parameters differ as below.
Model Exclusive Power & Current Parameters
- Input Power Supply: Single-phase 110V~230V AC ±10%, 50/60Hz industrial mains supply
- Continuous RMS Output Current: 6A
- Peak Output Current (500ms duration): 18A
- Built-In Shunt Regulator Performance: Continuous regenerative energy dissipation power 580W; matched external dynamic braking resistor resistance 18Ω
- Physical Dimension: Width 60mm, standard DIN rail vertical installation size
- Maximum Allowable Motor Cable Length: 40m with dedicated shielded servo composite cable
Core Function Features, Material Composition, Structural Characteristics, Working Principle, Application Scenarios, Installation Requirements, Use & Maintenance Precautions
All core functional logic, structural material composition, power conversion working principle, application scope, installation specifications and maintenance safety rules fully follow the unified framework defined for S30301-NA above. Exclusive differentiated features of S30361-NA are summarized as follows:
- Single-phase low-voltage AC input design adapts small factories and standalone automation equipment without three-phase high-voltage power supply conditions, directly connected to standard single-phase industrial power sockets without additional power transformation equipment.
- Higher continuous and peak output current supports medium torque servo motors with larger inertial loads, suitable for equipment with frequent high-load acceleration and deceleration cycles such as rotary packaging machines and fabric winding tension control equipment.
- Reserved multi-type fieldbus expansion card slots allow flexible upgrade of communication interfaces according to equipment upper control system configuration, compatible with mainstream industrial motion control bus protocols without replacing the entire servo drive unit.
