Product Short Description
Technical Specifications
- Input Voltage Range: 24 VDC (±10%)
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -55°C to +105°C
- Humidity: 5% to 95% non-condensing
- Communication Protocols: Modbus RTU, CANopen, Ethernet/IP
- Processing Speed: 100 MHz 32-bit microprocessor
- Memory: 512 KB RAM, 2 MB Flash
- Analog Inputs: 8 channels (0-10 V, 4-20 mA)
- Digital Inputs/Outputs: 16 configurable channels
- Certifications: CE, UL, ATEX, IECEx
Description
Functional Features
- Advanced Control Algorithms: Supports PID, fuzzy logic, and adaptive control for optimized performance.
- Real-Time Monitoring: Provides live data acquisition and diagnostics for operational parameters.
- Redundant Architecture: Dual-channel design ensures fail-safe operation and high reliability.
- User-Configurable Logic: Flexible programming via Woodward’s GAP software for custom application needs.
- Integrated Safety Functions: Complies with SIL 2/3 standards for critical shutdown and protection.
- Remote Accessibility: Enables remote configuration and troubleshooting through secure network interfaces.
Application Scenarios
- Power Generation: Governs speed and load control in gas, steam, and hydro turbines.
- Oil & Gas: Manages compressor and pump drives in upstream and downstream operations.
- Marine: Controls propulsion systems and auxiliary power units on vessels.
- Industrial Processes: Regulates mechanical drives in manufacturing and processing plants.
- Renewable Energy: Optimizes performance in wind and biomass power systems.
