Product Short Description
Technical Specifications
- Processor: Intel Pentium 4 (for controller variant).
- Memory: 1 GB RAM.
- Storage: 40 GB HDD.
- Communication Interfaces: RS-232, RS-422, RS-485, Ethernet.
- Power Supply: 24 V DC.
- Operating Temperature: -40°C to 70°C.
- Humidity: 5% to 95% (non-condensing).
- Protection Class: IP65.
- Redundancy: Supports redundant CPU, power supply, and communication.
- Safety Certification: Complies with IEC 61508 SIL 3 standards.
- Output Channels: 32 digital outputs (for DO module variant).
- Output Type: 24 V DC, sink-type (low-level effective).
- Output Current: Up to 0.5 A per channel.
- Response Time: ≤ 5 ms (channel delay).
- Isolation: Optically isolated per channel.
Description
Functional Features
- Triple Modular Redundancy (TMR): Three independent channels operate in parallel, ensuring fault tolerance and eliminating single points of failure.
- High Reliability: Designed for continuous operation in harsh industrial environments with minimal downtime.
- Hot-Swappable: Modules can be replaced online without interrupting system operation.
- Comprehensive Diagnostics: Real-time monitoring of module health, fault detection, and status indication via LEDs.
- Flexible Configuration: Supports multiple I/O types, including analog and digital inputs/outputs, for diverse applications.
- Security: Features access control, data encryption, and authentication to protect against unauthorized access.
- Scalability: Easily expands to accommodate increasing control demands with additional I/O modules.
Application Scenarios
- Safety Instrumented Systems (SIS): Used in emergency shutdown systems (ESD), fire and gas detection (F&G), and burner management systems (BMS) to ensure safe operation in high-risk industries.
- Process Control: Monitors and controls critical process parameters in refineries, offshore platforms, and LNG terminals.
- Power Generation: Ensures safe operation in nuclear and thermal power plants with real-time monitoring of reactor and turbine parameters.
- High-Precision Manufacturing: Supports flexible conveyor systems in automotive and electronics assembly lines for precise product positioning.
- Marine & Offshore: Used in drilling rigs and production platforms for fault-tolerant control in harsh environments.
Advantages
- Unmatched Reliability: TMR architecture eliminates single points of failure, ensuring continuous operation.
- Cost Efficiency: Reduces long-term maintenance costs through modular design and self-diagnostics.
- Versatility: Integrates seamlessly with diverse industrial networks via multiple communication protocols.
- Robustness: Withstands extreme temperatures, humidity, and vibrations for reliable performance in harsh environments.
- Scalability: Easily expands to meet evolving control needs without system overhaul.
