Product Short Description
- Technical Specifications
- Electrical Parameters
The operating voltage is 24V DC, and the power consumption is 3W, which realizes low – power operation and reduces the overall energy consumption of the system. Its frequency range covers 50 – 60Hz, which is fully compatible with the power frequency standards of industrial power grids in most regions. It is equipped with overload and short – circuit protection functions to avoid damage to the module due to electrical faults.
- I/O Configuration
It supports 32 digital input points or a 96 – point terminal block configuration, and can provide digital output or analog output such as 4 – 20mA signals. This multi – type I/O support enables it to connect with various sensors and actuators in industrial sites.
- Physical and Environmental Parameters
Its dimensions are 300 x 150 x 75mm and it weighs about 2kg. The compact size allows it to be easily installed in standard racks or control cabinets. It has an IP65 protection level and can work stably in an operating temperature range of – 20 to 60 degrees Celsius, resisting the impact of harsh environmental factors such as dust and moisture.
- Protocol and Certification Compliance
It supports industrial standard protocols including Modbus and Ethernet/IP, which ensures smooth data interaction with various industrial automation equipment and systems. It meets SIL 3 safety integrity level requirements certified by TÜV Rheinland, which fully complies with the safety standards of critical industrial application scenarios.
- Electrical Parameters
Description
- Functional Features
- Triple Modular Redundancy for High Reliability
It is composed of three independent processing units operating in parallel. When a single unit fails, the other two units can immediately take over its work. This design completely avoids system downtime caused by single – point faults and ensures the uninterrupted operation of the entire control system.
- Modular Design for Easy Maintenance and Expansion
The modular structure allows flexible configuration according to different industrial process requirements. During maintenance, the faulty module can be quickly disassembled and replaced without affecting the operation of other parts of the system. Meanwhile, it can be flexibly expanded according to the expansion of the production scale, which greatly reduces the difficulty and cost of system upgrading.
- Strong Real – time Data Processing Capability
It can quickly collect signals from on – site sensors and transmit control commands to actuators in real time. This rapid response capability enables the system to timely make safety interlocks and alarm responses to changes in process parameters such as pressure and temperature, avoiding potential safety hazards.
- Wide Compatibility for Flexible Integration
The compatibility with multiple industrial protocols enables it to establish connections with various distributed control systems and process automation systems. It can be easily integrated into existing industrial automation systems without the need for large – scale transformation of the original system, which improves the applicability of the module in different industrial scenarios.
- Triple Modular Redundancy for High Reliability
- Application Scenarios
- Petrochemical Industry
It is widely used in petrochemical plants as a key component of safety instrumented systems and emergency shutdown systems. It connects with on – site pressure sensors, temperature transmitters and emergency shut – off valves. It monitors process parameters in real time and triggers emergency shutdown procedures when abnormal data such as excessive pressure occurs, preventing accidents such as leaks and explosions.
- Power Generation Industry
In nuclear power stations and thermal power plants, it is applied to the control systems of key equipment such as boilers and turbines. It collects data from water level sensors, steam pressure detectors and speed monitors. It helps the system adjust operating parameters in a timely manner and implement load reduction or shutdown measures when equipment malfunctions, thus protecting the safe and stable operation of power generation units.
- Natural Gas Industry
It is deployed in natural gas processing plants and long – distance pipeline transmission systems. It connects with flow meters, gas concentration sensors and pipeline valve actuators. It realizes real – time monitoring of natural gas transmission volume and gas leakage. It ensures that once a dangerous situation arises, the relevant valves can be closed quickly to avoid gas leakage and subsequent explosion accidents.
- Chemical Industry
In chemical production workshops involving flammable and corrosive raw materials, it is integrated into the process control system. It is connected with reaction rate detectors, material level sensors and other equipment. It monitors the whole chemical reaction process. It assists the system in adjusting the feeding speed and reaction conditions, improving product quality and preventing safety accidents caused by abnormal reaction processes.
- Petrochemical Industry
