Applicable Temperature Matching: It is specially matched with the temperature management needs of Triconex chassis. It is used as a basic heat management component when the operating temperature is below 50°C, and needs to be used together with other enhanced heat dissipation measures when the temperature exceeds 50°C.
Chassis Compatibility: It is fully compatible with Triconex Tricon series chassis, including local chassis and expansion chassis used in high – density control systems, and matches the mechanical structure of the chassis slots.
Mechanical Design: The structural size is tailored to the Triconex chassis. It can be firmly installed on the chassis. The design is consistent with the overall mechanical layout of the Triconex module, and does not affect the installation and disassembly of other functional modules in the chassis.
Heat Conduction and Diversion: It guides the air flow inside the chassis, makes the heat generated by the internal electronic components circulate in an orderly manner, and improves the heat exchange efficiency between the chassis and the external environment.
Module Protection: While regulating heat, it forms a certain physical protection for the internal modules of the chassis, reducing the impact of external dust and slight vibration on the modules, and indirectly improving the stability of the modules.
Easy Installation: It is designed in line with the standardized installation method of Triconex accessories. It can be installed and fixed without complicated tools, and is compatible with the existing chassis structure without modifying the chassis.
Synergistic Heat Dissipation: It can work synergistically with multiple heat management measures such as shutters, pagoda tops, high – efficiency filters and redundant fans. It forms a multi – level heat dissipation system to cope with high – temperature operating environments.
Application Scenarios
Refining and Petrochemical Industry: It is applied to the Triconex safety instrumented system in oil refineries and petrochemical plants. These places have high temperature in the production area. The baffle ensures the stable operation of the chassis in the control systems such as emergency shutdown and burner management.
Oil and Gas Industry: It is used in the upstream and midstream Triconex control equipment of oil and gas. It helps the chassis maintain normal performance in the harsh on – site environment of oil fields and gas transmission pipelines, and ensures the operation of key systems such as high – integrity pressure protection.
Power Generation Industry: It is matched with the Triconex chassis in thermal power, nuclear power and other power plants. Nuclear power plants and thermal power plants have high requirements for the stability of control equipment. The baffle assists in heat management to support the continuous operation of turbine control and safety monitoring systems.
Chemical Industry: It is installed in the Triconex control chassis of chemical production workshops. Chemical production processes often produce a lot of heat. The accessory ensures that the safety control system for chemical reactions and material transmission will not be affected by high temperature.
Marine and Nuclear Equipment: It is used for Triconex – based control systems that have passed marine certification and nuclear 1E certification. It meets the strict heat management standards of marine ships and nuclear power plants, and provides guarantee for the safety operation of related equipment.
