Product Short Description
Technical Specifications
- Input Voltage: 93–132 VAC / 187–264 VAC (selectable)
- Output Voltage: 24 VDC
- Output Current: 24 A
- Power Rating: 576 W
- Efficiency: Up to 90%
- Operating Temperature Range: -25°C to 70°C (with derating above 50°C)
- Isolation Voltage: 1500 VDC
- Protection Class: IP20
- Certifications: CB, cCSAus, CE, cULus, cURus, EN 60950-1, EN 62368-1, UL 508
- Dimensions: 243 mm (L) × 83 mm (W) × 177.2 mm (H)
- Weight: 2 kg
Description
Functional Features
- High Reliability: Designed for continuous operation in harsh industrial settings with robust protection against overvoltage, overcurrent, and overheating.
- Wide Input Voltage Range: Supports global voltage standards (93–264 VAC) for flexible deployment.
- Compact and Modular Design: DIN-rail mounting enables easy integration into control panels, saving space and simplifying installation.
- High Efficiency: Up to 90% efficiency reduces energy consumption and heat generation, lowering operational costs.
- Signal Module (SIG): Provides AC power failure detection, DC-OK status indication, and remote on/off control for enhanced system monitoring.
- Low Ripple and Noise: Ensures stable power delivery for sensitive loads, minimizing interference in critical applications.
- Global Safety Approvals: Complies with international safety and EMC standards, ensuring compatibility across regions.
Application Scenarios
- Industrial Automation: Powers PLCs, sensors, actuators, and motor drives in manufacturing lines, robotics, and CNC machines.
- Mechanical Control: Supports hydraulic and pneumatic systems, conveyor belts, and packaging equipment.
- Process Control: Used in power plants, chemical processing, and water treatment facilities for reliable instrumentation and control.
- Railway and Transportation: Ensures stable power for signaling systems, rolling stock, and infrastructure monitoring.
- Test and Measurement: Provides clean power for laboratory equipment, data acquisition systems, and quality control devices.
- Lighting Systems: Drives LED lighting and other industrial lighting solutions with high efficiency.
Advantages
- Cost-Effective: Combines high performance with competitive pricing, offering a low total cost of ownership.
- Scalability: Modular design allows easy expansion or replacement in existing systems.
- Global Support: Backed by Traco Power’s worldwide service network and two-year product warranty.
- Proven Track Record: Trusted by leading industrial manufacturers for mission-critical applications.
