ProSoft RLX2-IHNF-W-E

Description

• Operating Temperature Range: – 40°F to 167°F (- 40°C to 75°C)
• Humidity: Up to 100% RH
• Ethernet Port: 1 water/dust – tight 10/100/1000 Base – T connector, shielded RJ45, compliant with IEEE 802.3, 802.3u, 802.3x, 802.3af

• Multiple Operation Modes: Supports access point, repeater, and client modes.
• High – speed and Stable Communication: 802.11n MIMO and channel bonding technology support demanding wireless applications such as Ethernet I/O and high – resolution video, providing excellent packet – per – second performance.
• Secure Networking: 802.11i, WPA – 2 personal/enterprise using 128 – bit AES encryption ensures secure networking. Radius security is also available for advanced authentication and encryption. Virtual local area networks (VLAN) allow for secure network segmentation.
• Quality of Service (QoS): Provides data prioritization for I/O control devices, video, data, etc.
• Ultra – fast Roaming: Ultra – fast roaming (under 10 ms) maintains seamless, high – speed connections to one or more devices on moving equipment and machines as they travel between access points.
• Diagnostic and Management: The included IH browser configuration and monitoring software allows the user to view network topology, assign IP addresses, monitor network diagnostics, and update radio firmware. Ethernet/IP – or Modbus – based PLCs/PACs can use message instructions to store diagnostic information from the radios, helping to reduce downtime when troubleshooting wireless network problems.

• Offshore Oil Rigs: Due to its IP66/67 rating, it is water – tight and can be used in extreme weather conditions on offshore oil rigs.
• Mining Applications: It is dust – tight and suitable for use in mining environments.
• Automated Storage – Retrieval Systems: The ultra – fast roaming feature makes it ideal for applications like automated storage – retrieval systems where devices need to move between access points.
• Automotive Skillet Lines: Can provide reliable wireless connectivity for automotive skillet lines.
• Bottle Filling Machines: Suitable for bottle filling machines and other manufacturing equipment that requires stable wireless communication for control and monitoring.
