Product Short Description
Technical Specifications
-
Power Rating: 400 W continuous, 1.1 kVA peak
-
Input Voltage: 1 × 120 / 240 VAC, 50 / 60 Hz
-
Continuous Output Current: 3 A RMS
-
Peak Output Current: 9 A (3 s)
-
Bus Voltage: 170 / 340 VDC
-
Control Supply: 24 VDC ±10 %, 0.2 A
-
Efficiency: > 95 %
-
Regenerative Braking: External resistor ready
-
Dimensions: 160 mm × 100 mm × 60 mm
-
Weight: 0.52 kg
Description
Functional Features
-
Auto-Configuration: Recognizes Parker smart-encoder motors; zero setup time
-
Control Modes: Position, velocity, torque, electronic gearing, electronic cam, programmable motion
-
Command Interfaces: ±10 V analog, STEP/DIR, RS-485, CANopen, EtherCAT option
-
Motor Support: Brushless servo, direct-drive servo, frameless servo, linear servo
-
Feedback Types: Incremental encoder, EnDat absolute encoder, resolver
-
Tuning Tools: On-board notch filters, auto-tuning wizard, Windows setup software
-
Protections: Over-current, over-voltage, over-temperature, short-circuit, motor thermal protection
-
LED Diagnostics: Power, fault, regeneration status indicators
-
Certifications: CE (EMC & LVD), UL 508c
Application Scenarios
-
Industrial Automation: Conveyor positioning, pick-and-place robots, rotary tables
-
CNC & Machine Tools: Spindle drives, feed axes, tool changers
-
Packaging Machinery: Film feed, sealing, labeling, cartoning systems
-
Test & Measurement: Dynamometer actuators, vibration test rigs
-
Printing & Textile: Web tension control, print-head positioning, yarn feeders
