Description

• Input Impedance: 10 MΩ minimum
• Isolation: 250 Vrms channel-to-channel, 500 Vrms channel-to-bus
• Data Buffer: 8 ksample FIFO
• Trigger Sources: Software, external TTL, or programmable timer
• Bus Interface: VME64x 64-bit, 320 MB/s peak throughput, supports block transfers
• Power Consumption: +5 V @ 800 mA typical, +12 V @ 200 mA
• Form Factor: 6U single-slot, 233 mm × 160 mm
• Operating Temperature: –40 °C to +85 °C
• Storage Temperature: –55 °C to +125 °C
• Humidity: 5 % to 95 % RH non-condensing
• Shock: 30 g operating, 50 g non-operating
• Vibration: 2.5 g operating, 5 g non-operating

• Simultaneous Sampling Support: External sample-and-hold on every channel eliminates phase skew
• Auto-Calibration: On-board precision reference and DACs enable automatic offset and gain correction
• Flexible Scanning: Programmable channel list and scan interval deliver custom acquisition sequences
• Real-Time Streaming: DMA engine transfers data to VMEbus memory with minimal CPU intervention
• Hot-Swap Ready: Conforms to VME64x hot-insertion specification
• Front-Panel Diagnostics: LEDs indicate power, activity, FIFO level, and error states

• Industrial Automation: Multi-loop temperature, pressure, and flow monitoring in chemical plants and refineries
• Aerospace & Defense: Flight-test instrumentation, engine health diagnostics, and wind-tunnel data acquisition
• Test & Measurement: Automated test equipment for power-supply validation, environmental stress screening, and sensor calibration racks
• Energy & Utilities: Substation SCADA, turbine performance analysis, and solar inverter string monitoring
