Product Short Description
- Transmission Type: High-precision planetary gear or harmonic drive (specific to BTC-304 series design).
- Torque Output: High torque capacity, suitable for robotic joints and heavy-duty machinery.
- Backlash: Ultra-low backlash (<1 arcmin), ensuring minimal positioning error.
- Repeatability: ±0.02 mm or better, critical for automated processes.
- Operating Temperature: -10°C to +60°C (standard), with options for extended ranges.
- Protection Class: IP65 (dustproof and water-resistant), enabling use in harsh environments.
- Mounting: Flange or shaft mounting for flexible integration.
- Lubrication: Long-life grease, reducing maintenance frequency.
- Communication: Supports industrial protocols like CANopen, EtherCAT, or Modbus (depending on configuration).
Description
Functional Features
- High Precision:
- Delivers sub-millimeter accuracy, ideal for semiconductor manufacturing, CNC machining, and medical robotics.
- Compact and Robust Design:
- Small footprint with high power density, saving space in tight installations.
- Built with high-grade materials (e.g., hardened steel gears) for durability.
- High Reliability:
- Designed for 24/7 operation with minimal downtime.
- Resistant to vibrations, shocks, and temperature fluctuations.
- Easy Integration:
- Compatible with major robot controllers (e.g., FANUC, ABB, KUKA) and PLCs.
- Modular interfaces for quick setup and scalability.
Application Scenarios
- Industrial Robotics:
- Powers joints in articulated robots for welding, painting, and assembly tasks.
- Used in collaborative robots (cobots) for safe human-machine interaction.
- Semiconductor Manufacturing:
- Enables precise wafer handling and inspection in cleanroom environments.
- CNC Machinery:
- Drives spindle motors and tool changers in milling, turning, and grinding machines.
- Medical Devices:
- Supports robotic surgery systems and imaging equipment for steady, controlled movements.
- Automated Guided Vehicles (AGVs):
- Provides steering and propulsion for material handling in warehouses and factories.
- Aerospace:
- Used in satellite positioning systems and drone flight control for high-stability performance.
Key Advantages
- Nabtesco’s Proven Technology:
- Leverages decades of expertise in precision gear systems, trusted by global leaders in robotics and automation.
- Cost Efficiency:
- Reduces total ownership costs through long service life and low maintenance requirements.
- Global Support:
- Backed by Nabtesco’s worldwide service network for spare parts, technical assistance, and training.
