MTL 5532 Pulse Isolation Barrier with Analog Output and Alarm Function

Description

• Hazardous Area Approvals:
  • Switch/proximity switch input: Zone 0, IIC, T6 (Group A)
  • Transmitter input: Zone 0, IIC, T4-T6 (Group A, with proper certification)
• LED Indicators:
  • Green: Power on
  • Yellow: Output circuit active
  • Red: Line fault or error detected

Functional Features

• Pulse Isolation: Isolates high-frequency pulse signals from hazardous areas to safe zones.
• Signal Conversion: Converts pulse signals into analog signals and configurable alarm point signals.
• Software Configuration: Pulse conversion parameters (e.g., switching points, hysteresis) can be set via computer software.
• Line Fault Detection (LFD): Detects open or short circuits in field wiring and triggers alarm outputs.
• NAMUR Compliance: Supports NAMUR-compliant sensors with adjustable switching points (3V, 6V, or 12V).
• High Isolation Voltage: Ensures electrical isolation between hazardous and safe areas, preventing interference.
• DIN Rail Mounting: Compact design for easy installation in control panels.
• LED Diagnostics: Visual indicators for power status, output activity, and fault conditions.

Application Scenarios

• Oil and Gas Industry: Monitors valve positions, pressure switches, or limit switches in explosive atmospheres.
• Chemical Processing: Safely isolates signals from sensors in corrosive or hazardous production areas.
• Power Generation: Isolates signals from high-voltage equipment to low-voltage control systems in power plants.
• Water and Wastewater Treatment: Controls pump and valve actuators while maintaining electrical isolation in wet environments.
• Pharmaceutical Manufacturing: Ensures electrical safety in clean rooms by isolating signals from fermentation tanks and temperature controllers.
• Mining Industry: Provides reliable signal transmission in underground mines for ventilation and gas monitoring systems.
• Factory Automation: Integrates with DCS (Distributed Control Systems) and PLC (Programmable Logic Controllers) for seamless automation control.
• Other Hazardous Areas: Suitable for any application requiring safe signal isolation in environments where explosive gases, vapors, or dust may be present.

Advantages

• Enhanced Safety: Intrinsic safety design prevents electrical sparks, making it suitable for Zone 0 hazardous areas.
• High Performance: Supports high-frequency pulse isolation and analog signal conversion for precise control.
• Flexible Configuration: Software-configurable parameters allow customization for different applications.
• Reliable Fault Detection: Line fault detection ensures system integrity by identifying wiring issues.
• Compact Design: DIN rail mounting saves space in control panels.
• Global Certifications: Meets international safety standards for global applications.
