Product Short Description
The IPMC712 is a multifunction PMC (PCI Mezzanine Card) I/O module that plugs onto Motorola / Emerson PowerPlus II VME single-board computers such as MVME5100, MVME5500 and MVME6100. It delivers legacy rear-panel connectivity and additional processing power in one compact mezzanine card.
Description
Technical Specifications
-
Processor: PowerPC 604e or Freescale MPC5200B running at 400 MHz or 800 MHz
-
Memory: 256 MB SDRAM and 512 MB on-board flash for firmware and data logging
-
Storage: Supports CompactFlash cards up to 1 GB
-
I/O Channels: 32 digital TTL inputs/outputs (programmable per byte)
-
Serial Ports: 2 × RS-232 / RS-485 (isolated)
-
Ethernet: 1 × 10/100 Mbit RJ-45
-
SCSI: 1 × Ultra-Wide SCSI port (68-pin, single-ended)
-
Parallel Port: 1 × IEEE-1284 compatible
-
Form Factor: Single-width, standard-length PMC card (IEEE P1386.1)
-
Power: +5 V and +3.3 V from PMC connector, typical 6 W
-
Operating Temperature: –40 °C to +85 °C
-
Dimensions: 310 mm × 230 mm × 65 mm (including heatsink)
-
Protection / Certification: IP65 front bezel, CE, UL, industrial EMC tested
Functional Highlights
-
Real-time processing with deterministic latency for closed-loop control
-
Full backward compatibility via MVME761 or MVME712M rear transition boards
-
Hot-swappable under VME64 hot-swap spec; no system shutdown required
-
On-board watchdog and temperature sensor with LED status indication
-
Field-upgradeable firmware via Ethernet or serial port
-
Security features: password-protected access, encrypted configuration file
Typical Application Scenarios
-
Industrial automation: motor drives, pumps, valve control on production lines
-
Process control: refineries, chemical plants, water treatment SCADA nodes
-
Power generation: turbine auxiliary monitoring, generator protection I/O
-
Robotics: motion controllers needing fast digital and serial interfaces
-
Test & measurement: ATE systems requiring high-speed parallel I/O and SCSI storage
