Product Short Description
Technical Specifications
- Control Modes: Supports position, speed, and torque control modes, with independent three-loop control (position, speed, torque) for high-precision synchronized motion.
- Feedback Compatibility: Compatible with mainstream feedback devices, including encoders, resolvers, and rotary transformers. Supports Hiperface DSL single-cable feedback technology for simplified wiring.
- Communication Interfaces:
- EtherCAT: Real-time Ethernet communication for distributed control architectures.
- CANopen: Industrial fieldbus for device-layer networking.
- Optional: RS232, pulse/direction interface, SynqNet (requires expansion module).
- Power Supply:
- Input voltage range: 110V–480V AC, compatible with global industrial power standards.
- Adapts to varying grid frequencies without additional configuration.
Description
- Environmental Adaptability:
- Dustproof and waterproof design (IEC 3M1 vibration resistance).
- Operates in extreme temperatures (-20°C to +60°C typical) and humidity (≤85% RH, non-condensing).
- Safety Certifications: Complies with IEC 61800-5-2 (STO), SIL2/SIL3 certifications, and international standards such as EAC, CE, UL, GOST-R, and TÜV.
Key Features
- High-Precision Control:
- Advanced motor control algorithms ensure smooth motion with minimal overshoot and oscillation.
- Speed response frequency of 1 kHz (typical) for rapid dynamic performance.
- Robust Design:
- Industrial-grade durability with anti-interference capabilities for harsh environments.
- Built-in protections against overcurrent, overvoltage, and overheating.
- Customization & Scalability:
- Supports 2CAN expansion modules for integrating safety function cards (e.g., SIL2/SIL3-certified).
- Memory card slot for parameter backup and firmware upgrades.
- User-Friendly Interface:
- Intuitive HMI simplifies parameter setup and debugging.
- Auto-detection of motor parameters optimizes control performance.
- Low Noise & Compact Size:
- Operates at 65 dB(A) (typical) for quiet environments.
- Compact design saves switchgear space; integrates power and brake resistors.
Applications
- Robotics: Precision control of robot joints and actuators for industrial and service robots.
- CNC Machinery: High-dynamic-response control of feed axes and spindles in machining centers.
- Packaging Machinery: Synchronized motion control for labeling, filling, and sealing equipment.
- Printing Machinery: Tension and speed coordination in printing and labeling machines.
- Semiconductor Equipment: Nanometer-level positioning for wafer handling and testing systems.
- Medical Devices: Accurate motion control in surgical robots and imaging equipment.
- Aerospace: Flight control systems and positioning tasks in aircraft and spacecraft.
- Elevators & Lifts: Smooth motion and floor-level positioning in building elevators.
Additional Capabilities
- Programmability: Built-in IEC 61131 macro programming language for flexible motion logic development.
- Cogging Effect Suppression: Algorithms reduce low-speed jitter for smoother operation.
- Global Certifications: Ensures compliance with international safety and quality standards for global deployment.
