Electrical Parameters: It works with 24VDC systems and supports a maximum voltage of 36VDC which meets IEC 1010 overvoltage category 3 standards. Each channel has a maximum continuous current of 1.5A and can deliver more than 110mA current with current limiting function. The power consumption is 5mA per channel plus the output load, and the maximum load per output can reach 2.5 watts at 24VDC. The voltage drop is less than 1.5VDC at 110mA, and the off current is less than 0.1mA.
Physical and Installation Parameters: Its dimensions are 6cm × 7cm × 5.8cm and it weighs 0.63kg. It mounts on standard TS32/TS35 DIN rails and occupies 61mm of rail space. The module uses screw terminals that can accept wires up to 2.5mm². The wire strip length needs to be 7mm, and the terminal tightening torque is fixed at 0.5Nm.
Environmental and Safety Parameters: The conformal coating version meets IEC 60664 – 3 Type A requirements for pollution degree 1 areas. In hydrogen environments, it has 3.0mH inductance and 0.2μF capacitance; in non – hydrogen environments, the inductance is 12mH and capacitance is 5μF. It has obtained multiple international certifications including CE, TÜV, UL, CSA and FM, and is certified for Class I, Division 2 hazardous locations.
High Safety and Compliance: It holds SIL 2/3 certifications and complies with IEC 61508 functional safety standards. The current – limited output design prevents ignition risks, which makes it fully applicable to hazardous industrial locations and effectively avoids safety accidents caused by electrical faults.
Independent Channels Ensure Stable Operation: It is configured with eight independent digital output channels that can control multiple external devices simultaneously without mutual interference. This separate channel design ensures that the malfunction of one channel will not affect the normal operation of other channels, improving the overall stability of the system.
Convenient Installation and Wiring: It adopts a universal snap – in design for quick installation on standard DIN rails. The secure screw terminals ensure reliable field wiring connections, reduce the difficulty of on – site installation and wiring, and save installation time and labor costs for industrial projects.
Strong Environmental Adaptability: The conformal coating on the specific version protects the module against environmental contamination. This structural design enables the module to resist the erosion of moisture, dust and other harmful substances, allowing it to maintain stable performance in harsh industrial environments.
Application Scenarios
Petrochemical Industry: It integrates into emergency shutdown systems and gas detection systems in petrochemical plants. It connects with on – site gas sensors and emergency cut – off valves. When toxic or flammable gases exceed the standard, it sends digital signals to quickly trigger valve closure and equipment shutdown, avoiding explosion and leakage accidents.
Machinery Manufacturing Industry: It is applied to machine safety systems such as stamping machines and automated assembly lines. It links with safety light curtains and emergency stop buttons. When operators accidentally enter dangerous areas, the module immediately outputs control signals to stop the operation of the machine, protecting the personal safety of operators.
Power Generation Industry: It is used in the safety control systems of thermal power and nuclear power plants. It is connected to turbine protection devices and fire alarm systems. When abnormalities such as equipment overheating or fire occur, it controls the start – up of fire – fighting equipment and the shutdown of related power – generation equipment to minimize loss of equipment and ensure the safety of the power – generation process.
Building and Industrial Park Security: It is deployed in access control systems and fire alarm systems of large industrial parks and high – rise industrial buildings. It controls the opening and closing of access gates and the activation of fire sprinklers. When a fire is detected, it can trigger the fire alarm and start the fire – fighting equipment in a timely manner, while restricting irrelevant personnel from entering the dangerous area.
