HONEYWELL CC-PCNT02 – High-Speed Redundant Process Control Module

Description

• Channels: 8 isolated 4–20 mA inputs with built-in HART
• Accuracy: ±0.05 % of span
• Pulse counter: up to 50 MHz, 32-bit resolution
• Communication
  – Dual gigabit FTE (Fault Tolerant Ethernet) ports, < 1 s switch-over
  – Protocols: Modbus RTU/TCP, Profinet, EtherNet/IP, DNP3
  – Redundant IOLINK to I/O cards
  – GPS time-sync input
• Power: 24 VDC (18–32 V range)
• Operating temperature: –40 °C to +70 °C
• Protection: IP20 standard, conformal-coated IP54 optional
• Mechanical: Series C 6U single-slot, 1.7 kg
• Certifications: CE, ATEX, IECEx, SIL 2/3

• Redundant hot-standby design with ECC memory and Flash CRC
• Native HART diagnostics, asset management without external multiplexer
• Hot-swappable for zero-downtime maintenance
• Custom Algorithm Blocks (CAB) and Profit Loop for advanced control
• 1 ms SOE resolution for fault analysis
• Low power draw: 1.8 W typical, ideal for remote or battery-powered sites

• Oil & gas: wellhead control, pipeline leak detection, refinery process loops
• Chemical & pharma: batch reactor control, cleanroom monitoring
• Power generation: turbine governing, substation automation, gas flow metering
• Water & wastewater: online water-quality monitoring, remote pump start/stop
• Logistics & manufacturing: robot coordination, conveyor pulse counting and closed-loop speed control
