Honeywell 51401286-100 Enhanced Peripheral Display Generator (EPDG) Card

Description

• Functional Features
  • Integrated Multi – function Control: It integrates multiple functions such as video display signal generation, peripheral equipment control and multi – device communication. It avoids the complexity caused by configuring multiple separate modules, simplifies the system structure and reduces the difficulty of system integration.
  • Wide – ranging System Compatibility: It can not only be seamlessly integrated with Honeywell’s own Experion PKS and ControlEdge PLC systems, but also be compatible with a large number of modules. The extensive compatibility allows it to be flexibly applied to different customized industrial control schemes.
  • Intuitive Operation and Maintenance: It supports touch screen operation and is equipped with LED indicators to display power supply, communication and alarm status in real time. It also can be equipped with a 2×16 – bit LCD display, which allows maintenance personnel to quickly grasp the module’s operating status and locate faults.
  • Reliable Fault Linkage Protection: When acting as a temperature alarm interface module, it can set high and low temperature alarm thresholds. Once the detected temperature exceeds the threshold, it will trigger a relay output and link with the control system to realize automatic protective measures such as shutdown, so as to avoid equipment damage.
  • Easy Installation and Expansion: It adopts a modular design and supports DIN rail installation. The installation process is simple and can be adapted to the compact layout of industrial control cabinets. The modular structure also facilitates later expansion and replacement, reducing maintenance time and costs.
• Application Scenarios
  • Petrochemical Industry: It is installed in the control system of oil refineries and chemical plants. It collects temperature, pressure and flow signals of reaction kettles and pipelines through matching sensors. It displays real – time data through its own display function and links alarm mechanisms to prevent safety accidents such as overheating and excessive pressure of equipment.
  • Power Generation Industry: It is applied to the control system of thermal power plants and hydropower stations. It is connected with generator sets, transformers and other key equipment to monitor the operating parameters of the equipment in real time. It transmits data to the central control room through communication interfaces and assists operators in making timely regulation and control decisions.
  • General Manufacturing Industry: It is deployed on automated assembly lines of electronic components and automobile manufacturing. It controls the communication between assembly robots, conveyor belts and central controllers. It displays the operating status of each station in real time and sends out alarms for abnormal situations such as workpiece clamping deviation and equipment shutdown, ensuring the smooth progress of the assembly line.
  • Industrial Universal Station Monitoring: As a display generator card for universal station nodes, it is used in the central monitoring stations of various large industrial parks. It integrates data from multiple on – site devices, generates complex graphical displays such as detailed charts and curves, and helps managers comprehensively grasp the overall operation of the industrial park.
  • Temperature – sensitive Equipment Monitoring: In industries such as food processing and pharmaceutical production that have strict temperature requirements, it is used with RTD detectors. It monitors the temperature of drying equipment and constant – temperature workshops in real time. It triggers alarms and adjusts temperature – control equipment in time when the temperature deviates from the set range to ensure product quality.
