Product Short Description
Technical Specifications
-
Sensor Interface: 1 × 50-pin D-Sub connector
-
Gas Types: Combustible, toxic, and inert (range customizable per order)
-
Detection Technology: Infrared absorption
-
Power Supply: 24 V DC ±10 %
-
Power Consumption: 5 W typical
-
Accuracy: ±1 % full-scale linearity & repeatability
Description
-
Electronic Drift: <2 % per 6 months
-
Dimensions: 140 mm × 210 mm × 40 mm (DIN 3106 form factor)
-
Enclosure: IP65-rated, dust-tight and water-resistant
-
Operating Temperature: –40 °C to +85 °C
-
Humidity: 20 % to 90 % RH non-condensing
-
Weight: 0.165 kg (card only), 2 kg shipping weight
Functional Features
-
Plug-and-Play Calibration: On-board non-volatile memory stores span and zero coefficients; calibration executed via front-panel push-buttons or Modbus commands
-
Triple Alarm Relays: A1, A2, A3 relays rated 250 V AC / 5 A; individually programmable for rising or falling alarm levels
-
Status LEDs: Red (alarm), yellow (fault), green (power) and back-lit LCD bar graph for instantaneous gas concentration, peak hold, numeric readout and diagnostics
-
Configurable Output: 4–20 mA linear or 0–10 V isolated analog output plus RS-485 Modbus RTU for remote monitoring and SCADA integration
-
Hot-Swap Ready: Card slides into System 57 rack without powering down adjacent modules
-
Failsafe Operation: Watchdog timer forces outputs to safe state on CPU or sensor fault
Application Scenarios
-
Oil & Gas Refineries: Continuous hydrocarbon monitoring around flares, tanks, and loading racks
-
Chemical Plants: Toxic gas detection in reactor buildings and solvent storage areas
-
Power Generation: Hydrogen and CO monitoring in turbine enclosures and battery rooms
-
Water Treatment: Chlorine and ozone detection in dosing and contact chambers
-
Marine & Offshore: Inert-gas blanketing on LNG carriers and FPSO platforms
