GE VME162PA-344SE-2G VME Embedded Controller

Description

Technical Specifications

Core Processing

• Processor: Motorola MC68040, 33 MHz 32-bit CPU with integrated floating-point unit
• ASIC: Second‑generation Petra ASIC for optimized memory and I/O control
• Watchdog Timer: Hardware programmable watchdog for system fault recovery
• Real‑Time Clock: Battery‑backed RTC for persistent timekeeping
• Non‑Volatile Memory: 8KB NVRAM for critical configuration storage

Memory & Storage

• System Memory: 2 GB SDRAM (ECC‑enabled for data integrity)
• Flash Memory: On‑board Flash for boot firmware and user applications
• Storage Interfaces:
  • 1 × SCSI port for mass storage devices
  • IDE interface for HDD/SSD expansion
• Boot Options: Flash, SCSI, IDE, and network PXE boot

I/O Interfaces

• Ethernet: 1 × 10/100BASE‑TX Ethernet port
• Serial: 2 × serial ports (1 × EIA‑232‑D DCE console, 1 × configurable EIA‑232‑D/EIA‑422/EIA‑485)
• Parallel: 1 × Centronics parallel port
• Expansion: 4 × IndustryPack (IP) slots for custom I/O module integration
• VMEbus: Full VMEbus interface with P1/P2 connectors, supporting VMEbus master/slave operation

Electrical & Mechanical

• Form Factor: 6U Eurocard (single‑slot VMEbus)
• Power Input: +5 VDC, +12 VDC, -12 VDC from VME backplane
• Power Consumption: Max 12 W
• Dimensions: 233.4 mm × 160 mm × 20.3 mm (6U standard)
• Weight: Approx. 0.5 kg

Environmental Ratings

• Operating Temperature: 0°C to +60°C (standard); -40°C to +85°C (optional extended)
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5%–95% RH (non‑condensing)
• Vibration: 5g RMS (10–500 Hz)
• Shock: 15g (20 ms half‑sine)
• Certifications: CE, FCC, RoHS compliant

Key Features

• High‑Performance 32‑Bit Processing: 33 MHz MC68040 CPU delivers reliable computing for real‑time control and data processing.
• IndustryPack Expansion: Four IP slots enable flexible I/O customization for application‑specific requirements.
• Comprehensive I/O Suite: Integrated Ethernet, SCSI, serial, and parallel ports for versatile system connectivity.
• ECC Memory Support: Error‑correcting code memory ensures data integrity in critical applications.
• Rugged Industrial Design: Extended temperature and mechanical ratings for harsh industrial and defense environments.
• VMEbus Compatibility: Operates as VMEbus master or slave in standard VME architectures.
• Built‑In Reliability: Hardware watchdog, battery‑backed RTC, and NVRAM for stable long‑term operation.
• OS Support: Compatible with VxWorks, Linux, and other real‑time operating systems.
• Flexible Boot Configuration: Multiple boot sources support diverse deployment scenarios.

Application Scenarios

• Industrial Automation: Factory automation, PLC/DCS systems, motion control, and process monitoring.
• Defense & Aerospace: Avionics processing, military ground control, radar data handling, and rugged vehicle systems.
• Energy & Power: Substation automation, generator control, and grid monitoring systems.
• Oil & Gas: Drilling rig control, pipeline monitoring, and offshore platform embedded systems.
• Test & Measurement: High‑speed data acquisition, automated test equipment, and industrial inspection systems.
• Transportation: Railway signaling, marine automation, and heavy vehicle management.
• Telecommunications: Network equipment control and embedded communication servers.
