Product Short Description
-
Product Overview
Microprocessor-based, self-powered feeder protection relay designed for medium-voltage (5–15 kV) fused switchgear. Provides comprehensive protection, monitoring, and arc-flash mitigation for industrial and utility feeders . -
Electrical Specifications
-
Rated voltage: 100–240 V AC/DC auxiliary or self-powered from CTs
-
Frequency: 50/60 Hz ±10 %
-
Current inputs: 1 A or 5 A (phase and ground)
Description
-
Voltage inputs: 120/240 V phase-phase via optional VT
-
Overcurrent ranges: 0.1–25 A (1 A CT) / 0.5–125 A (5 A CT)
-
Trip outputs: 2 Form-C contacts, 5 A @ 250 V AC
-
Auxiliary outputs: 4 programmable Form-C contacts
-
Protection & Functions
-
Phase overcurrent (51/50)
-
Ground overcurrent (51N/50N)
-
Negative-sequence overcurrent (46)
-
Breaker failure protection (50BF)
-
Arc-flash reduction logic with instantaneous trip
-
Built-in event recorder and fault logger
-
Mechanical & Environmental
-
Dimensions: 177 mm H × 140 mm W × 144 mm D
-
Weight: 1.8 kg (4 lbs)
-
Enclosure: IP40 front, ANSI Type 1
-
Operating temperature: –40 °C to +70 °C
-
Certifications: UL 508, IEC 60255, CE
-
Communications
-
RS-485 Modbus RTU standard
-
Ethernet option for Modbus TCP
-
Functional Highlights
-
Arc-flash mitigation reduces incident energy
-
Dial-and-LED interface simplifies commissioning
-
Self-powered mode eliminates external supply
-
Compact footprint fits ANSI switchgear compartments
-
Application Scenarios
-
Industrial plant feeder protection (manufacturing, data centers)
-
Metal-clad and metal-enclosed switchgear
-
Mining conveyor and motor feeder protection
-
Utility distribution substations
-
Renewable-energy interconnection
