Product Short Description
Technical Specifications
- Power Supply: Dual-redundant DC (9-36) V, typical 24 V DC, with DC1500 V isolation and reverse polarity protection.
- Input/Output Capacity:
- Discrete Inputs: Up to 24 channels (contact inputs).
- Discrete Outputs: Up to 12 relay outputs (C-type relays).
- Communication:
- Two 10/100 Mbps Ethernet ports (RJ45 connectors) for redundant network connectivity.
- Supports DeviceNet, CANOpen, and CAN BUS protocols via optional 5-pin terminal interfaces.
- Environmental Tolerance:
- Operating Temperature: 0°C to 60°C (standard), -40°C to +85°C (extended option).
- Storage Temperature: -40°C to +85°C.
- Relative Humidity: ≤90% (non-condensing).
Description
- Mechanical Design:
- Dimensions: 132 mm × 105 mm × 52 mm (H × D × W).
- Weight: 800 g.
- Enclosure: IP30-rated aluminum casing with wave-pattern reinforcement for durability.
- Mounting: 35 mm DIN rail installation.
- Protection Features:
- Surge Protection: 4000 V lightning protection.
- Overcurrent Protection: 1.5 A fuse.
- Fiber Optic Support: Optional SC/FC/ST connectors for long-distance communication (up to 20 km).
Functional Features
- High Reliability:
- Redundant power inputs and Ethernet ports ensure continuous operation during power or network failures.
- Soft-start circuit manages current surges during power-up, extending component lifespan.
- Flexible Configuration:
- Supports TDBS end terminal boards for simplex applications and TDBT boards for TMR systems.
- Compatible with SRLY relay and STCI contact input terminal boards for mixed I/O setups.
- Advanced Diagnostics:
- LED indicators provide real-time status feedback (power, network, and I/O activity).
- Built-in self-test routines verify hardware integrity during startup.
- Signal Integrity:
- Optical isolation (up to 1500 V) on inputs protects against voltage spikes.
- Hardware filtering (4 ms response time) minimizes noise interference.
- Security:
- Fiber optic link fault detection alerts users to communication disruptions.
- Relay告警 outputs (DC48 V/1 A) trigger alarms for power or network failures.
Application Scenarios
- Power Generation:
- Controls gas and steam turbines in power plants, ensuring stable grid frequency and voltage.
- Manages generator paralleling and reactive power compensation for efficient energy distribution.
- Oil and Gas:
- Monitors pipeline pressure and valve positions in refineries and offshore platforms.
- Facilitates emergency shutdown systems (ESD) for safety-critical operations.
- Industrial Automation:
- Regulates motor control centers (MCCs) in manufacturing plants for precise equipment operation.
- Supports batch processing in chemical and pharmaceutical industries.
- Water Treatment:
- Controls pump stations and filtration systems to maintain water quality and supply.
- Marine Engineering:
- Manages propulsion systems and auxiliary generators on ships for reliable navigation.
Key Advantages
- Scalability: Modular design allows easy expansion to meet evolving industrial needs.
- Cost Efficiency: Redundant features reduce downtime, lowering maintenance and operational costs.
- Global Compliance: Meets CE, UL, and RoHS standards for international market adoption.
- Seamless Integration: Works natively with GE Mark VIe controllers and supports ToolboxST software for configuration and monitoring.
