Product Short Description
Technical Specifications
-
Rated Voltage: 230 V AC
-
Motor Compatibility: MTR-series permanent-magnet servo motors
-
Control Modes: Position, speed, torque
-
Positioning Accuracy: Sub-micron resolution via high-resolution encoder interface
-
Supports incremental and absolute encoders
-
-
Sampling / Response: High-speed DSP loop, sub-millisecond dynamic response
-
Discrete I/O: Multiple digital inputs and outputs for limit switches, sensors, solenoids
-
Analog I/O: ±10 V differential inputs and outputs for pressure, temperature, or torque sensors
-
Clock Function: Real-time clock for time-stamped motion profiles and diagnostics
Description
-
Communication Protocols:
-
Ethernet/IP
-
Modbus TCP / RTU
-
CANopen
-
DeviceNet (via option module)
-
-
Mounting: DIN-rail or panel mount with IP20 protection
-
Operating Temperature: 0 °C to 55 °C
-
Storage Temperature: –40 °C to 85 °C
-
Humidity: 5 % to 95 % RH non-condensing
-
Shock: 30 g operating / 50 g non-operating
-
Vibration: 2.5 g operating / 5 g non-operating
Functional Features
-
Embedded Magnet Speed Control: Uses rotor-saliency feedback for sensorless high-efficiency operation
-
Multi-Axis Synchronization: Network-based real-time coordination for gantry, robotic, and packaging lines
-
Auto-Tuning & Diagnostics: Built-in oscilloscope and frequency-response analysis tools
-
Programmable Logic: User-defined motion blocks and safety interlocks via ladder or structured text
-
Energy Optimization: Regenerative braking and torque-sharing algorithms reduce power consumption
-
Hot-Plug Module Support: Option cards for additional I/O or fieldbus expansion without power-down
Application Scenarios
-
High-Speed Manufacturing Lines: Synchronizes conveyors, pick-and-place robots, and vision systems in electronics and automotive plants
-
Precision Machining: Controls CNC axes and tool changers with micron-level accuracy
-
Packaging & Filling: Coordinates multi-axis form-fill-seal machines for consistent product weight and seal integrity
-
Chemical & Oil & Gas: Drives agitators, pumps, and valve actuators in corrosive or explosive atmospheres
-
Automotive Assembly: Manages robotic welding, gluing, and inspection stations with real-time quality feedback
-
Renewable Energy: Positions solar trackers and adjusts wind-turbine pitch blades for maximum energy capture
