GE IC693MDL940 Digital Relay Output Module

• Switching Time:
  • ON to OFF: 15 ms (maximum)
  • OFF to ON: 15 ms (maximum)
• Surge Current Capacity: 5 A (maximum)
• Isolation:
  • Field-to-logic side: 1500 VAC (group-to-group)
  • 500 VAC (between groups)
• Power Consumption:
  • 5 VDC backplane bus: 7 mA (all outputs on)
  • 24 VDC relay bus: 135 mA (all outputs on)
• LED Indicators: Provides status feedback for module and individual channel operations.

Functional Characteristics

• High-Density Outputs: 16 relay outputs in a single module reduce cabinet space requirements.
• Flexible Voltage Support: Accommodates both AC and DC voltage ranges for compatibility with various field devices.
• Reliable Isolation: Protects against electrical noise and surges, enhancing system stability.
• Status Monitoring: LED indicators enable real-time monitoring of module and channel states.
• Mechanical Keying: Prevents incorrect placement of similar PLC modules.
• Hot-Swappable: Can be replaced without powering down the system, minimizing downtime.

Application Scenarios

• Industrial Automation: Controls actuators, solenoids, and motors in assembly lines, packaging machinery, and CNC machines.
• Process Control: Manages valve positions, pump statuses, and safety interlocks in chemical, petrochemical, and water treatment plants.
• Energy Management: Interfaces with power distribution equipment in substations and renewable energy systems.
• Material Handling: Monitors conveyor systems, photoelectric switches, and limit switches in warehouses and distribution centers.
• Building Automation: Controls HVAC systems, lighting, and access control in smart buildings for energy efficiency.
