Product Introduction
The GE EPSCPE100-ABAC is a standalone controller under the PACSystems RSTi-EP series, designed to deliver high-performance control in a compact form factor for industrial automation applications. It integrates a 32-bit processor, 1 MB of user memory, and multi-protocol communication capabilities, supporting PROFINET, PROFIBUS, EtherCAT, Modbus TCP/IP, and OPC UA for seamless integration with industrial networks and devices. The controller features a DIN rail-mountable design, 24 VDC power input, and a wide operating temperature range of -25°C to +70°C, suitable for harsh industrial environments. It offers 2K discrete I/O points and 32K words of analog I/O capacity, with built-in SRTP client/server and EDG communication functions for real-time data exchange. It holds Achilles Level 2 certification for communication reliability, and complies with UL, ATEX, IECEx, CE, and RoHS standards, ensuring safety and compatibility across global industrial setups. The controller supports programming via PACSystems software, enabling quick configuration and seamless integration with RSTi-EP I/O modules for scalable control solutions.
Description
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | GE PACSystems RSTi-EP Series |
| Model | EPSCPE100-ABAC |
| Product Type | Standalone Industrial Controller |
| Processor | 32-bit industrial-grade processor for real-time control |
| User Memory | 1 MB for program and data storage |
| Power Supply | 24 VDC (19.2–28.8 VDC operating range) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% RH (non-condensing) |
| Mounting | DIN rail mounting (35 mm standard) |
| I/O Capacity | 2K discrete I/O points, 32K words analog I/O |
| Communication Ports | 1x PROFINET port, 1x USB-A 2.0 port, 1x RS-232 port |
| Supported Protocols | PROFINET RT/IRT, PROFIBUS DP, EtherCAT, Modbus TCP/IP, OPC UA Server, SRTP Client/Server, EDG |
| Certifications | Achilles Level 2, UL Ordinary Locations, UL Hazloc, ATEX, IECEx, CE, FCC, RoHS |
| Dimensions | Approx. 100 mm × 150 mm × 50 mm |
| Weight | Approx. 0.3 kg |
| Power Consumption | Max. 10 W (24 VDC) |
| Data Retention | Non-volatile memory for program and data storage |
Functional Features
- High-Performance Processing: 32-bit processor ensures fast execution of control logic, handling complex automation tasks with low latency.
- Multi-Protocol Communication: Supports PROFINET, PROFIBUS, EtherCAT, Modbus TCP/IP, and OPC UA, enabling connectivity with diverse industrial devices and networks.
- Compact DIN Rail Design: Saves cabinet space, simplifies installation, and allows for flexible placement in control panels.
- Wide Temperature Range: Operates from -25°C to +70°C, withstanding extreme temperature fluctuations in industrial settings.
- Scalable I/O Capacity: 2K discrete I/O points and 32K words of analog I/O accommodate growing application needs.
- Real-Time Data Exchange: SRTP client/server and EDG functions enable real-time communication with PACSystems controllers and HMI devices.
- Achilles Level 2 Certified: Ensures communication reliability and resistance to cyber threats in industrial networks.
- Global Compliance: UL, ATEX, IECEx, CE, and RoHS certifications guarantee safety and compatibility across international industrial standards.
- User-Friendly Programming: Compatible with PACSystems software, supporting structured text, function block diagram, and ladder logic programming.
- Non-Volatile Memory: Preserves program and data during power loss, eliminating the need for battery backup.
- Integrated Diagnostics: Built-in diagnostic tools provide real-time status updates and fault alerts for rapid troubleshooting.
- Seamless System Expansion: Works with RSTi-EP I/O modules for plug-and-play expansion, adapting to changing control requirements.
Application Scenarios
- Manufacturing Automation: Controls assembly lines, packaging machinery, and material handling systems, coordinating discrete and analog I/O for efficient production workflows.
- Process Control in Petrochemical Plants: Manages temperature, pressure, and flow in distillation units and reactors, using multi-protocol support to integrate with process sensors and valves.
- Power Generation Auxiliary Systems: Controls boiler feedwater pumps, cooling towers, and emission monitoring systems in thermal power plants, ensuring stable operation.
- Water and Wastewater Treatment: Manages pump stations, filtration systems, and chemical dosing processes, with wide temperature tolerance for outdoor installations.
- Building Automation: Integrates with HVAC, lighting, and security systems via Modbus TCP/IP and BACnet, optimizing energy use in commercial buildings.
- Renewable Energy Systems: Controls solar inverters, wind turbine pitch systems, and battery storage units, supporting high-speed communication with SCADA systems.
- Automotive Production Lines: Coordinates robotic arms, conveyor belts, and quality inspection equipment, using EtherCAT for precise motion control.
- Food and Beverage Processing: Manages pasteurization, filling, and packaging lines, complying with hygiene standards and ensuring consistent product quality.
- Marine and Offshore Systems: Withstands vibration and temperature extremes to control shipboard power distribution and navigation systems.
- Industrial IoT (IIoT) Gateways: Acts as a data hub, collecting sensor data and transmitting it to cloud platforms via OPC UA for predictive maintenance and remote monitoring.
