GE 8913-PS-AC PAC8000 Series AC-to-DC Industrial Power Supply Module

Description

Technical Specifications

• Power Input and Output Parameters
  • The AC input voltage range covers 85 – 264VAC, which can adapt to voltage fluctuations in different regions and power grids.
  • It provides dual DC output voltages: 12VDC with an output current of 5A and 24VDC also with an output current of 5A, meeting the power demands of different industrial devices.
  • The power conversion efficiency can reach up to 95%, minimizing energy loss and reducing heat generation during operation.
  • The output voltage accuracy is maintained at ±1%, ensuring the stable operation of precision control equipment.
• Environmental Adaptability Parameters
  • The operating temperature range is from -40°C to 70°C, and it can achieve full rated output even at an ambient temperature of 70°C.
  • The storage temperature range is -40°C to 85°C, and it can withstand a relative humidity of 93% at 40°C for 56 consecutive days without affecting performance.
  • The maximum operating case temperature is set at 80°C, which can cope with the high – temperature environment inside industrial control cabinets.
