Type: Field-mounted controller / vibration & pressure monitoring module
Brand: Foxboro (now Schneider Electric)
Part Number: H92904CC0500
Type: Field-mounted controller / vibration & pressure monitoring module
Brand: Foxboro (now Schneider Electric)
Part Number: H92904CC0500
Technical Specifications
-
Input: 24 VDC or 12–48 VDC power, 4–20 mA / 0–10 V pressure or vibration sensor inputs
-
Output: 4–20 mA, 0–10 VDC and RS-485 Modbus RTU communication
-
Accuracy: ±0.05 % F.S. for pressure measurement
-
Response Time: <5 ms for vibration events
-
Operating Temperature: –40 °C to +85 °C (basic module)
-
Power Module Variant: 115/230 VAC in → 24 VDC @ 10 A out, –20 °C to +60 °C
Description
-
Mechanical: 50 × 50 × 20 mm (sensor) or 170 × 105 × 32 mm (power)
-
Weight: 120 g (sensor) / 2 kg (complete controller)
-
Protection: IP20 (basic) or IP54 conformal-coated (harsh duty)
Functional Features
-
Dual role: pressure transmitter controller and vibration monitor in one unit
-
High-precision 24-bit A/D with automatic temperature compensation
-
Redundant RS-485 and 4–20 mA outputs for fail-safe links
-
On-board 32-bit RISC processor for local diagnostics and logging
-
Hot-swap capability and front-panel LEDs for status/fault indication
-
Configurable alarm set-points, dead-bands, and delay timers via PC software
Applications
-
Oil & Gas: wellhead pressure, pipeline vibration monitoring
-
Chemical & Petrochemical: reactor pressure, pump vibration
-
Power Generation: steam header pressure, turbine bearing vibration
-
Pharmaceutical: sterile vessel pressure, agitator imbalance detection
-
Water & Waste-water: pump pressure, blower vibration
