Product Short Description
Technical Specifications
- Output & Communication Parameters
- It has 8 isolated output channels, compatible with HART instruments complying with HART specification versions 5, 6, and 7.
- The analog output accuracy between 4mA and 20mA reaches ±0.05% of full scale, with a 13-bit resolution and a maximum output load of 750Ω.
- The maximum signal change rate achieves 20mA within 60 milliseconds, and it can transmit two digital messages per second with each HART field device, operating at a baud rate of 1200 in point-to-point master-slave asynchronous half-duplex mode.
- It complies with HART FSK physical layer specification HCF_SPEC-54 revision 8.1, and the maximum distance between the module and field devices extends to 3030 meters.
- Electrical Specifications
- It uses a 24V DC redundant power supply with a voltage tolerance of ±5%, a maximum power consumption of 7W, and a maximum heat dissipation of 5W.
- Each channel is furnished with an isolated power supply, and all analog outputs are current-limited to approximately 25mA under normal operation. Each data byte is protected by parity check, and each message is equipped with a CRC check byte to ensure communication accuracy.
Description
- Physical & Environmental Specifications
- It has dimensions of 4.5cm × 11cm × 11.5cm and a shipping weight of 0.32kg, while the shipping weight for logistics purposes is listed as 2.0kg in some supply chain records.
- The operating temperature range of the module and its PA termination assembly is -20°C to +70°C, and it adapts to 5% – 95% non-condensing humidity.
- It can operate at an altitude of -300 meters to 3000 meters and resist vibration of 7.5m/s² within the frequency range of 5 – 500Hz.
Function Features
- Full Isolation Design Improves Anti-Interference Capability
All 8 output channels are galvanically isolated from each other, as well as from the ground and module logic. Each channel is also equipped with current limiting and voltage regulation functions. This design completely eliminates signal crosstalk between channels, prevents module damage caused by voltage surges or electromagnetic interference, and ensures stable signal output in complex industrial electromagnetic environments.
- Dual Signal Output and Versatile Command Support
Each channel can flexibly switch between 4 – 20mA analog signals and HART FSK digital signals, supporting mixed connection with standard analog devices and HART intelligent devices without hardware modification. It supports HART universal, common practice, and device-specific commands, enabling the DCS to not only send control signals but also obtain detailed device status and diagnostic information.
- Rugged Structure and Intuitive Status Monitoring
The extruded aluminum shell provides strong physical protection for internal circuits, allowing the module to withstand harsh conditions such as dust, vibration, and chemical corrosion on industrial sites. The front-panel LED indicators clearly display the module’s operating status and channel communication activities, enabling maintenance personnel to quickly identify and troubleshoot issues.
- Easy Integration and Long-Distance Transmission
It is fully compatible with the Compact 200 series I/O subsystem and can achieve functions previously provided by the 100 series FBM I/O subsystem when matched with appropriate termination assemblies. It supports local or remote field wiring connections via termination assemblies, and its 3030-meter maximum transmission distance fully meets the wiring requirements of large-scale industrial sites.
Application Scenarios
- Oil and Gas Industry
It is deployed in oil drilling platforms, natural gas processing plants, and long-distance pipelines. It connects with HART control valves and flow meters, outputting 4 – 20mA control signals to adjust the flow of oil and gas media. It simultaneously retrieves device wear and pressure loss data through HART communication, helping operators optimize transmission efficiency and prevent pipeline leaks or blockages.
- Chemical Industry
It is installed on chemical reaction lines, connected with HART actuators and dosing pumps on reactors and mixing tanks. It sends precise current signals to control the dosage of raw materials and reaction temperature. By receiving diagnostic information from field devices, it predicts potential failures of pumps and valves, ensuring continuous and safe operation of chemical synthesis processes.
- Power Industry
It is applied in coal-fired, gas-fired, and nuclear power plants, matching with HART positioners on boiler combustion systems and steam valve actuators. It outputs control signals to adjust fuel injection volume and steam flow, while collecting equipment operating parameters such as valve opening and actuator temperature. It helps the central control system maintain stable boiler operation and avoid equipment damage caused by parameter deviations.
- Pharmaceutical Industry
It is integrated into pharmaceutical production lines for drug synthesis and filling. It connects with HART flow meters and pressure control devices in reaction kettles and filling machines. It precisely controls the addition of raw materials and filling pressure to meet GMP standards. Real-time communication with HART devices ensures traceability of process parameters and improves the consistency and qualification rate of pharmaceutical products.
- Food and Beverage Industry
It is used in pasteurization lines, beverage blending equipment, and canning production lines. It links with HART temperature controllers and flow valves, outputting signals to regulate pasteurization temperature and material flow rate. It monitors the working status of key devices through HART communication, preventing unqualified products due to temperature or flow fluctuations and ensuring food safety and quality stability.
