Product Short Description
Technical Specifications
- Electrical Parameters
- The input voltage range covers 85 – 264 volts alternating current, and the input frequency ranges from 47 – 63 hertz, which is compatible with the mainstream power grid standards in most countries and regions around the world.
- It stably converts alternating current to 12 volts direct current for output, matching the power requirements of Secure Stack C2 Ethernet switches.
- The output current ranges from a minimum of 1.0 ampere to a maximum of either 8.5 amperes or 13.0 amperes, and the continuous maximum output power corresponds to 102 watts or 156 watts respectively to meet different power load demands of switches.
- It achieves high – efficiency AC – to – DC conversion, which reduces energy loss during the power conversion process and lowers overall energy consumption.
- Physical Specifications
- The module has dimensions of 19.6 centimeters × 5.2 centimeters × 25.7 centimeters, which fits the 19 – inch rack mounting standard and facilitates unified installation and layout in equipment cabinets.
- The net weight of the module is 1.75 kilograms, and the maximum weight including packaging and auxiliary components reaches 4.26 kilograms, which is lightweight enough to not impose excessive load on rack structures.
- Reliability & Auxiliary Features
- The mean time between failures reaches 300,000 hours, which reflects its outstanding long – term stable operation capability and reduces the frequency of maintenance and replacement.
- It is equipped with status LED indicators that provide intuitive visual feedback on the module’s power input, output, and operating status, enabling maintenance personnel to quickly identify faults.
- It is designed to be used with compatible chassis such as C2RPS – CHAS2 or C2RPS – CHAS8, which can be directly connected to the supported switches for quick integration.
Description
Function Features
- Redundant Power Supply Guarantee
As a redundant power supply module, it automatically takes over the power supply task immediately when the primary power supply fails. This seamless switchover ensures that the connected Secure Stack switches continue to operate normally, completely avoiding network interruptions caused by power outages.
- Hot – swapping Capability
The hot – swapping design allows maintenance personnel to replace the module during the operation of the connected switches. This eliminates the need to shut down the entire network or switch equipment during maintenance, maximizing the uptime of the network infrastructure.
- Wide Voltage Compatibility
The 85 – 264 volts alternating current input range enables the module to adapt to unstable power grid environments. It can maintain stable power output even when there are fluctuations in the input voltage, protecting the connected switches from damage caused by voltage instability.
- Plug – in & Easy Integration
Its plug – in design allows it to slide smoothly into compatible chassis. It does not require complex wiring or modification work during installation. It can be seamlessly integrated with Secure Stack C2 Ethernet switches, significantly reducing the difficulty of deployment and commissioning.
- Intuitive Status Monitoring
The built – in status LED indicators display the working status of the module in real time. Maintenance staff can quickly determine whether the module is in normal operation, power failure, or other abnormal states at a glance, which shortens the troubleshooting time and improves the efficiency of equipment maintenance.
Application Scenarios
- Enterprise Core Networks
It is deployed in the core network equipment rooms of large enterprises, such as financial institutions and large – scale manufacturing companies. These enterprises rely heavily on stable network connections for daily business operations like data transmission and business system operation. The module ensures that the core switches maintain continuous operation, preventing economic losses and work disruptions caused by network outages due to power problems.
- Industrial Automation Networks
It is applied in industrial automation production workshops, including automotive manufacturing plants, chemical production bases, and electronic component processing workshops. In these environments, industrial control systems and production line monitoring equipment are connected through Secure Stack switches. The module provides reliable redundant power supply to avoid production line shutdowns caused by power failures, ensuring the continuity and stability of the production process.
- Data Centers
Data centers host a large number of servers and network switches that need to operate 24 hours a day. The Foxboro C2RPS – PSM module is used to supply power to the Secure Stack switches in data centers. It works with the primary power supply system to ensure that data transmission between servers and external networks is not interrupted, protecting the security and integrity of data and meeting the high availability requirements of data centers.
- Government & Public Service Institutions
It is installed in the network equipment of government offices, public security command centers, and medical institutions. These institutions need to maintain uninterrupted network services to handle emergency affairs, such as emergency command and medical data transmission. The module provides a reliable power backup guarantee, ensuring that their core network equipment can operate stably at all times and supporting the smooth development of public services.
- Telecommunication Infrastructure
It is used in telecommunication base stations and regional communication hubs. These facilities use Secure Stack switches to manage the transmission of communication signals. The module ensures that the switches are not affected by power fluctuations or sudden power outages, maintaining the stability of signal transmission. This helps to avoid communication disruptions for users in the coverage area and guarantees the quality of telecommunication services.
