Description
Technical Specifications
-
Architecture: modular 3 RU card (119 mm × 94 mm) for 19-inch rack
-
Power: 24 V DC nominal, reverse-polarity and short-circuit protected
-
Processor: high-performance industrial micro-controller
-
Memory: on-board Flash for firmware and user programs
-
Signal inputs
– eddy-current, Hall-effect and magnetic VR speed sensors
– two isolated 0/4–20 mA current outputs (±1 % FS)
– four digital inputs (24 V DC, opto-isolated) -
Update rate: 60 Hz loop frequency, response < 2 µs
-
Isolation: 2.5 kV channel-to-system
-
Environmental: -20 °C to +65 °C operating, -40 °C to +70 °C storage, IP20 front
Functional Highlights
-
Open programming: C, C++, Python for custom control and protection logic
-
Hot-swap modules enable on-line expansion and replacement
-
Integrated overspeed detection with configurable trip curves and alarm outputs
-
Built-in vibration monitoring algorithms for early machinery diagnostics
-
Redundant Ethernet fieldbus ports for seamless communication with PLC or DCS
-
Front-panel LEDs and diagnostic registers for rapid fault location
Applications
-
Turbine, compressor and pump overspeed protection in power plants and oil & gas facilities
-
Vibration and speed monitoring on motors, gearboxes and fans
-
Digital I/O expansion in chemical, pharmaceutical and manufacturing automation systems
-
Retrofit upgrades to legacy PLC or DCS architectures for enhanced safety and diagnostics
