Product Short Description
- Input Voltage: 48 V DC (compatible with industrial power systems)
- Continuous Current: 30 A
- Peak Current: 80 A
- Output Power: Up to 30 kW (application-dependent)
- Communication Protocols: Supports EtherCAT for high-speed data transmission and real-time control, enabling synchronization in multi-axis systems.
- Control Modes: Position, speed, and torque control with high-resolution feedback (e.g., 20-bit encoders).
- Efficiency: ≥98%, minimizing energy loss and heat generation.
- Operating Temperature: 0°C to +40°C (optional high-temperature version up to +55°C).
- Storage Temperature: -25°C to +70°C.
Description
- Protection Class: IP20 (front panel).
- Cooling: Natural or forced air cooling (application-dependent).
- Dimensions: Compact design for space-saving integration.
Functional Features
- High Dynamic Response:
- Delivers rapid acceleration/deceleration for high-speed positioning and complex trajectory control.
- High Power Density:
- Compact size with high current output, ideal for space-constrained applications.
- Advanced Control Algorithms:
- Precision control of position, speed, and torque with minimal overshoot and settling time.
- Real-Time Ethernet Communication:
- EtherCAT protocol enables low-latency data exchange (<1 ms) for synchronized multi-axis motion.
- Safety and Reliability:
- Built-in protection against overcurrent, overvoltage, undervoltage, overheating, and short circuits.
- Complies with safety standards (e.g., IEC 61800-5-2 SIL3, EN ISO 13849-1 PL e).
- Modular Design:
- Supports various motor types (e.g., permanent magnet synchronous, DC brushed, linear motors).
- Multiple interfaces for flexible system integration.
Application Scenarios
- Industrial Robotics:
- Powers joints in multi-axis robots, AGVs (Automated Guided Vehicles), and collaborative robots (cobots) for precise motion and force control.
- Semiconductor Manufacturing:
- Used in wafer handling, dicing, and inspection equipment for nanometer-level positioning accuracy.
- CNC Machinery:
- Drives spindles and feed systems in milling, turning, and grinding machines for high-speed, high-precision machining.
- Medical Devices:
- Enables precise motion in MRI, CT scanners, and robotic surgery systems for diagnostic and therapeutic applications.
- Aerospace and Defense:
- Supports high-reliability applications like drone stabilization, missile guidance, and satellite positioning.
- Packaging and Logistics:
- Controls conveyors, pick-and-place robots, and sorting systems for efficient material handling.
Key Advantages
- Efficiency: Reduces operational costs through minimal energy waste and heat generation.
- Scalability: Adapts to diverse applications with modular hardware and software configurations.
- Global Compliance: Meets international safety, EMC, and environmental standards (e.g., UL, CE, IEC).
- 24/7 Reliability: Designed for continuous operation in harsh conditions with robust thermal management.
- Expert Support: Backed by Elmo’s global service network for technical assistance and spare parts.
