Product Short Description
Display & Touch
• Size / Type: 10.4-inch TFT colour, VGA 640 × 480 pixels
• Brightness: 350 cd m⁻², contrast 350:1
• Colours: 65 536 or 256 selectable
• Back-light: dual CCFL, 50 000 h life, software-dimmable
• Touch: infra-red 79 × 59 channel matrix behind laminated safety glass, non-reflective, multi-touch capable
Description
Processing & Memory
• CPU: 32-bit RISC, 400 MHz
• DRAM: 64 MB (OS, program, data)
• Flash: ≈ 1.5 MB user-available for data backup
• NVRAM: 32 KB retained data
• Storage: 2 × CompactFlash Type I/II slots (system & user cards)
• RTC battery: non-replaceable CR2032, 10-year hold-up
• CPU: 32-bit RISC, 400 MHz
• DRAM: 64 MB (OS, program, data)
• Flash: ≈ 1.5 MB user-available for data backup
• NVRAM: 32 KB retained data
• Storage: 2 × CompactFlash Type I/II slots (system & user cards)
• RTC battery: non-replaceable CR2032, 10-year hold-up
Interfaces – Built-in
• Ethernet: 10/100 Base-TX (RJ-45)
• Serial: 1 × RS-232 (SUB-D 9)
• Fieldbus: 1 × CAN / easyNet (SUB-D 9, galvanically isolated)
• USB: 2 × Host USB 2.0 + 1 × Device USB 1.1
• Expansion: 2 empty slots for pluggable comm. cards (PROFIBUS-DP, MPI, EtherNet/IP, etc.)
• Ethernet: 10/100 Base-TX (RJ-45)
• Serial: 1 × RS-232 (SUB-D 9)
• Fieldbus: 1 × CAN / easyNet (SUB-D 9, galvanically isolated)
• USB: 2 × Host USB 2.0 + 1 × Device USB 1.1
• Expansion: 2 empty slots for pluggable comm. cards (PROFIBUS-DP, MPI, EtherNet/IP, etc.)
Software & Programming
• Operating system: Windows CE (requires license)
• Visualisation: GALILEO, EPAM, XSOFT-CODESYS-2, XSOFT-CODESYS-3
• PLC run-time: user-installable with LIC-PLC-MXP-MEDIUM (IEC 61131-3, all five languages)
• Operating system: Windows CE (requires license)
• Visualisation: GALILEO, EPAM, XSOFT-CODESYS-2, XSOFT-CODESYS-3
• PLC run-time: user-installable with LIC-PLC-MXP-MEDIUM (IEC 61131-3, all five languages)
Power & Environment
• Supply: 24 V DC SELV, 20.4-28.8 V DC operational, 19.2-30.0 V DC absolute
• Power draw: 14 W typical, 32 W max (incl. 2 comm. + 2 USB modules)
• Operating temp: 0 °C … +50 °C
• Storage / transport: −20 °C … +60 °C
• Humidity: 10 % … 95 % RH non-condensing
• Protection: IP65 front (NEMA 4X equivalent), IP20 rear
• Shock / vibration: IEC 60068-2-27/-64, 5 g operational
• Approvals: cULus (UL508), ATEX II 3D Ex II T70 °C IP5x Zone 22, CE, EN 61000-6-2/-3/-4, EN 61131-2
• Supply: 24 V DC SELV, 20.4-28.8 V DC operational, 19.2-30.0 V DC absolute
• Power draw: 14 W typical, 32 W max (incl. 2 comm. + 2 USB modules)
• Operating temp: 0 °C … +50 °C
• Storage / transport: −20 °C … +60 °C
• Humidity: 10 % … 95 % RH non-condensing
• Protection: IP65 front (NEMA 4X equivalent), IP20 rear
• Shock / vibration: IEC 60068-2-27/-64, 5 g operational
• Approvals: cULus (UL508), ATEX II 3D Ex II T70 °C IP5x Zone 22, CE, EN 61000-6-2/-3/-4, EN 61131-2
Housing & Mounting
• Front: brushed stainless steel, satin finish, laminated safety glass
• Rear: metal anodised enclosure
• Dimensions (front plate): 345 mm W × 260 mm H
• Mounting: flush-mount, spring clamps, cut-out 310 mm × 225 mm × 55 mm depth
• Front: brushed stainless steel, satin finish, laminated safety glass
• Rear: metal anodised enclosure
• Dimensions (front plate): 345 mm W × 260 mm H
• Mounting: flush-mount, spring clamps, cut-out 310 mm × 225 mm × 55 mm depth
Key Functional Highlights
• High-resolution real-time graphics with trend, recipe, alarm, and data-logging objects
• Multi-protocol gateway: Modbus RTU/TCP, EtherNet/IP, CANopen, SUCONET, KNX, DeviceNet, etc.
• 200 password levels, 100 on-line languages, graphical user-interface designer
• Hot-plug CF cards for firmware, application, and recipe updates
• Integrated web server and FTP for remote diagnostics
• High-resolution real-time graphics with trend, recipe, alarm, and data-logging objects
• Multi-protocol gateway: Modbus RTU/TCP, EtherNet/IP, CANopen, SUCONET, KNX, DeviceNet, etc.
• 200 password levels, 100 on-line languages, graphical user-interface designer
• Hot-plug CF cards for firmware, application, and recipe updates
• Integrated web server and FTP for remote diagnostics
Typical Application Scenarios
• Machine-tool control panels, packaging lines, robotic cells
• Process skids, mixers, filling and dosing systems
• Building automation (HVAC, lighting, access)
• Water & wastewater treatment plants
• Food & beverage, pharmaceutical batch control with CFR 21 Part 11 audit trails
• Machine-tool control panels, packaging lines, robotic cells
• Process skids, mixers, filling and dosing systems
• Building automation (HVAC, lighting, access)
• Water & wastewater treatment plants
• Food & beverage, pharmaceutical batch control with CFR 21 Part 11 audit trails
Ordering Content
• XV-440-10TVB-1-50 HMI-PLC terminal
• Stainless-steel front foil with laminated glass
• Mounting gasket and spring clamps
• Quick-start guide (multilingual)
• Licensing and CF-card options ordered separately:
– LIC-PLC-MXP-MEDIUM (IEC 61131-3 run-time)
– CF-Cards (512 MB … 8 GB, industrial grade)
• XV-440-10TVB-1-50 HMI-PLC terminal
• Stainless-steel front foil with laminated glass
• Mounting gasket and spring clamps
• Quick-start guide (multilingual)
• Licensing and CF-card options ordered separately:
– LIC-PLC-MXP-MEDIUM (IEC 61131-3 run-time)
– CF-Cards (512 MB … 8 GB, industrial grade)
