Product Short Description
Technical Specifications:
- Ethernet Interface:
- 2 × RJ45 ports (10/100 Mbps, auto-negotiation)
- Supports full-duplex/half-duplex operation
- Protocol Support:
- PROFINET RT/IRT
- EtherNet/IP (CIP)
- Modbus TCP
- TCP/IP, UDP, HTTP, FTP
- Data Throughput: Up to 100 Mbps per port
- Latency: <1 ms (PROFINET IRT)
- Isolation: Channel-to-channel isolation (1.5 kV AC)
- Power Supply: 24VDC (±20%)
- Power Consumption: ≤5W
- Operating Temperature: -20°C to +60°C
- Storage Temperature: -40°C to +85°C
- Dimensions: 125mm (W) × 115mm (H) × 20mm (D)
- Weight: 120g
- Mounting: 35mm DIN rail
- Certifications: CE, UL, cUL, RoHS
Description
Functional Features:
- Multi-Protocol Support: Simultaneous operation of PROFINET, EtherNet/IP, and Modbus TCP for cross-vendor compatibility.
- Real-Time Performance: PROFINET IRT ensures deterministic communication with sub-millisecond latency.
- Redundant Networking: Dual Ethernet ports enable fault-tolerant ring topologies.
- Security:
- Built-in firewall with access control lists (ACLs).
- Secure boot and firmware update authentication.
- VPN support for encrypted remote access.
- Diagnostics:
- Real-time link status monitoring.
- Packet error detection and auto-recovery.
- LED indicators for port activity, errors, and link speed.
- Easy Configuration: Software-based setup via B&R Automation Studio.
Application Scenarios:
- Manufacturing Automation:
- Connecting PLCs, HMIs, and robots in smart factories.
- Real-time motion control and synchronization.
- Process Industries:
- Data acquisition from sensors in chemical plants.
- Remote monitoring of oil and gas pipelines.
- Energy Sector:
- Grid automation and substation communication.
- Wind turbine and solar inverter networking.
- Transportation:
- Railway signaling and control systems.
- Electric vehicle charging station networks.
- Building Automation:
- HVAC and lighting system integration.
- Fire alarm and security networks.
Advantages:
- Interoperability: Supports major industrial Ethernet protocols, eliminating compatibility issues.
- High Performance: Low-latency communication for time-critical applications.
- Reliability: Redundant ports and robust diagnostics minimize network downtime.
- Security: Advanced protection against cyber threats safeguards industrial control systems.
- Scalability: Compact design allows easy integration into existing automation architectures.
- Global Compliance: Meets international standards for safety and electromagnetic compatibility.
