Product Short Description
Technical Specifications
- Sensitivity: 20 mV/mm/s (±5% tolerance at 100 Hz)
- Frequency Response: 10 Hz (600 cpm) to 1 kHz (60,000 cpm) with ±3 dB tolerance
- Output Signal: Voltage proportional to vibration velocity (self-generating, no external power needed)
- Cable Configuration:
- Standard Cable: 2-core shielded twisted pair, 22 AWG (0.5 mm²), moisture-resistant connectors
- Armored Cable Option: Stainless steel armor for enhanced durability in abrasive environments
- Maximum Cable Length: 305 meters (1,000 feet) between sensor and monitoring system
- Operating Temperature: -29°C to +121°C (-20°F to +250°F)
- Storage Temperature: -29°C to +121°C (-20°F to +250°F)
- Relative Humidity: Up to 95% non-condensing
- Mounting: M10X1 double-ended stud or 1/2-20 UNF-3A bolt
- Weight: Approximately 480 grams (17 ounces)
- Enclosure Material: Corrosion-resistant stainless steel housing
Description
Key Features
- Moving-Coil Design: Minimizes sensitivity to shock and pulse excitation for stable measurements in dynamic environments.
- Self-Generating Output: Eliminates need for external power supplies, simplifying installation.
- Harsh Environment Durability: Built-in corrosion resistance and optional armored cabling for extended service life.
- High Sensitivity: Detects low-level vibrations (0.1 mm/s to 50 mm/s velocity range) for early fault diagnosis.
- Industry-Standard Compatibility: Works seamlessly with Bently Nevada 3500/42, 1900/65, and 2300/20 monitoring systems, as well as third-party vibration analyzers.
Application Scenarios
- Power Generation: Turbines, generators, and compressors in thermal, hydro, and wind power plants.
- Oil & Gas: Pumps, motors, and centrifuges in upstream drilling, midstream pipelines, and downstream refining.
- Petrochemicals: Reactors, extruders, and fans for process reliability in chemical manufacturing.
- Steel Industry: Rolling mills, blast furnaces, and conveyor systems for vibration monitoring.
- Manufacturing: CNC machines, spindles, and assembly line equipment for precision control.
- Marine & Offshore: Propulsion systems and deck machinery in marine vessels and offshore platforms.
Industry Compliance
- Meets API 670 standards for machinery protection systems.
- Certified for hazardous environments (ATEX Zone 2, IECEx, and CSA Class I Division 2 approvals available).
Benefits
- Predictive Maintenance: Enables early detection of imbalances, misalignments, and bearing wear to prevent unplanned downtime.
- Cost Reduction: Extends equipment lifespan by facilitating timely maintenance interventions.
- Safety Enhancement: Mitigates catastrophic failures through real-time vibration alerts.
- Operational Efficiency: Reduces manual inspection needs via continuous automated monitoring.
- Centralized Management: Integrates with Bently Nevada’s System 1 platform for enterprise-wide asset health tracking.
