Product Short Description
Technical Specifications:
- Channels: 2 independent proximity transducer input channels.
- Input Type: Compatible with Bently Nevada-approved proximity probes (e.g., 3300 XL series).
- Measurement Range:
- Radial Displacement: 0 to 1000 µm (0 to 40 mils) peak-to-peak.
- Axial Displacement: 0 to 500 µm (0 to 20 mils) peak-to-peak.
- Frequency Response: DC to 10 kHz.
- Accuracy: ±1% of full scale for displacement measurements.
- Signal Processing:
- RMS, peak, and peak-to-peak measurement options.
- Bandpass filtering for isolating specific frequency bands.
- Environmental Resistance:
- Operating Temperature: -40°C to +85°C (-40°F to +185°F).
- Humidity: Up to 95% non-condensing.
- Protection: IP66-rated for dust and water resistance.
- Power Consumption: 6 W per module.
- Certifications: Meets API 670 (machinery protection systems) and SIL 2-certified for safety applications.
Description
Functional Features:
- Real-Time Displacement Monitoring: Continuously measures radial and axial shaft position to detect early signs of mechanical degradation.
- Programmable Alarms: User-configurable thresholds for warning and danger levels, enabling proactive maintenance.
- Multi-Parameter Support: Monitors displacement, velocity, and acceleration (when paired with accelerometers).
- Advanced Signal Conditioning: Filters out noise and electrical interference to ensure accurate data.
- Diagnostic LEDs:
- OK LED: Indicates normal operation.
- Alarm LED: Signals when displacement exceeds set thresholds.
- Bypass LED: Shows bypass mode activation.
- Seamless Integration: Works with the 3500 system rack and System 1 software for centralized data analysis and trending.
- Flexible Configuration: Supports customization of measurement ranges and frequency bands.
Application Scenarios:
- Turbomachinery: Monitors shaft vibration and position in steam turbines and gas turbines to detect resonance or imbalance.
- Generators: Tracks radial and axial displacement in rotor systems to prevent bearing failures.
- Compressors: Analyzes shaft position in centrifugal and reciprocating compressors to avoid mechanical collisions.
- Pumps: Detects misalignment in centrifugal pumps to prevent seal leakage and bearing damage.
- Motors: Monitors rotor position in electric motors to identify early signs of wear.
- Marine/Offshore: Safeguards propulsion systems on ships by detecting shaft misalignment or excessive vibration.
Key Advantages:
- High Precision: Sub-1% measurement accuracy for reliable fault detection.
- Rugged Design: Withstands extreme temperatures, humidity, and vibrations in industrial environments.
- Scalability: Supports up to 14 monitor modules in a single 3500 series rack.
- Cost Efficiency: Reduces downtime and maintenance costs through predictive maintenance enabled by continuous monitoring.
- Customizable: Adjustable measurement ranges and frequency bands to suit specific application needs.
- Safety Compliance: SIL 2-certified for use in safety-critical applications.
