Product Category: Eddy – current proximitor sensor for displacement and vibration measurement
Operating Voltage: Works with a 10 – 32V DC power supply to adapt to different industrial power supply configurations
Output Signal: Supports linear analog output, which can be configured into 4 – 20mA current output or 0 – 10V voltage output according to actual application needs
Measurement Performance: The peak – to – peak measurement range of vibration and displacement reaches 0.1 – 1000μm, and the measurement accuracy is ±1% of the full scale
Frequency Response: Covers a frequency range of 0 – 10kHz, which can fully meet the monitoring requirements of various rotating machinery
Temperature Tolerance: The operating temperature range is – 40°C to +85°C; the storage temperature range is expanded to – 55°C to +100°C
Physical Parameters: The length is 75mm, the diameter is 12mm, and the weight is 0.25kg; the overall dimensions of the integrated system are 8cm×6.1cm×6.3cm when including the matching connection components
Structural Details: The housing is made of rugged stainless steel; it adopts standard M4 threaded mounting and also supports panel mounting methods
Protection Level: Has an IP67 protection rating, achieving dust – tight performance and resistance to water jets from all directions
Certifications: Obtains CSA, ATEX and IECEx certifications to meet the safety and quality standards of multiple industrial regions
Dual – mode Precision Measurement: Realizes both static position measurement and dynamic vibration measurement. It can capture tiny changes in the position and vibration of machinery, providing accurate data support for judging equipment wear, misalignment and other faults
Full Component Interchangeability: The probe, extension cable and proximitor sensor in the system can be completely interchanged. No separate component matching or bench calibration is required during replacement, which greatly simplifies maintenance procedures
Strong Backward Compatibility: It is fully compatible and interchangeable with probes and extension cables of non – XL 3300 series, especially applicable to scenarios where the 8mm probe is too large and a 5mm probe needs to be installed, reducing the cost of equipment upgrade and replacement
Strong Anti – interference and Environmental Adaptability: The stainless steel housing resists corrosion and wear. It has strong immunity to radio frequency interference and can maintain stable signal transmission in complex electromagnetic environments. The IP67 protection level and wide temperature operating range allow it to work stably in harsh industrial conditions
Easy Integration and Installation: It supports multiple flexible mounting methods to fit different machinery structures. The reliable connector design ensures stable signal transmission, and it can be seamlessly integrated with various Bently Nevada monitoring systems and mainstream industrial DCS systems
Application Scenarios
Fluid – film Bearing Machinery Field: It is widely used for vibration and position measurement of fluid – film bearing machines. It can accurately monitor the shaft movement status of such equipment, avoid faults caused by bearing wear or oil film instability, and ensure the smooth operation of the machinery
Oil and Gas Industry: Installed on centrifugal compressors, pipeline pumps and drilling rig rotating components in oil refineries and gas fields. It adapts to the high – pressure and dusty on – site environment and provides early warning for equipment faults to prevent leakage and other major safety accidents
Power Generation Industry: Deployed on steam turbines, generators and hydropower units in thermal power plants and hydropower stations. It monitors key parameters such as shaft vibration and displacement in real time, ensuring the continuous and stable operation of power generation equipment and avoiding power outages caused by equipment failures
Keyphasor and Speed Measurement: Applied to keyphasor reference and speed measurement scenarios of various rotating machinery. It provides accurate speed data and phase reference signals for the overall control system of the equipment, laying a foundation for the precise control of the production process
General Manufacturing and Metallurgy Industry: Used for condition monitoring of motors, gearboxes and rolling mill rotating parts in manufacturing workshops and steel plants. It helps the maintenance team carry out predictive maintenance, reduce the frequency of equipment shutdown for maintenance, and improve the continuity and efficiency of the production line
Reviews
There are no reviews yet.
Be the first to review “Bently Nevada 330180-91-05 3300 XL Proximitor Sensor” Cancel reply
