Product Short Description
Technical Specifications
- Sensor Type: Dual-channel eddy current proximity sensor interface.
- Channels: Two independent channels (Channel A and Channel B).
- Measurement Range:
- Radial displacement: Up to ±2.54 mm (±0.100 in) peak-to-peak.
- Axial displacement: Up to ±6.35 mm (±0.250 in).
- Linearity: ±1% of full-scale output over the specified range.
- Sensitivity: 8 mV/μm (200 mV/mil) at standard operating conditions.
- Frequency Response: DC to 10 kHz (adjustable for application-specific needs).
- Output Signal: Voltage (±10 VDC max) compatible with monitoring systems and data acquisition devices.
- Supply Voltage: 24 VDC ±10% (powered via system rack or external power supply).
- Operating Temperature:
- Module: 0°C to +65°C (+32°F to +149°F).
- Sensor (remote): -40°C to +125°C (-40°F to +257°F).
Description
- Environmental Rating:
- Module: IP20 (protected against solid objects >12.5 mm).
- Sensor: IP67 (dust-tight and protected against temporary immersion).
- Cable Compatibility: Works with Bently Nevada standard extension cables (5 m to 9 m lengths).
- Target Material: Conductive metals (e.g., steel, stainless steel, aluminum).
- Weight: 0.5 kg (1.1 lbs) per module.
Key Features
- Dual-Channel Design: Simultaneously monitors two sensor inputs for comprehensive machinery analysis.
- High-Resolution Measurement: Detects micro-displacements (as low as 0.5 μm / 0.00002 in) for early fault detection.
- Real-Time Data Processing: Provides instantaneous feedback on shaft position and vibration.
- Self-Diagnostic Capabilities: Monitors sensor health, cable integrity, and module status with alert outputs.
- Rugged Construction: Built to withstand industrial environments with vibration, electromagnetic interference, and temperature extremes.
- Plug-and-Play Integration: Seamlessly connects with Bently Nevada monitoring systems (e.g., System 1, 3500 Series).
- Adjustable Filtering: Configurable low-pass and high-pass filters to reduce noise and isolate critical frequencies.
Application Scenarios
- Turbomachinery: Monitoring rotor vibration and thrust position in gas turbines, steam turbines, and centrifugal compressors.
- Power Generation: Detecting shaft misalignment and unbalance in generators and hydroelectric turbines.
- Oil & Gas: Measuring vibration in reciprocating compressors, pumps, and downhole drilling equipment.
- Aerospace: Testing engine components and rotor systems for vibration and balance in aviation applications.
- Industrial Manufacturing: Tracking spindle displacement in CNC machines, rolling mills, and paper machinery.
- Marine Propulsion: Monitoring shaft alignment and vibration in propulsion systems for ships and submarines.
Industry Compliance
- API 670: Certified for machinery protection systems in critical rotating equipment.
- ATEX Zone 2/IECEx: Approved for use in hazardous environments (explosion-proof versions available).
- ISO 9001: Manufactured under strict quality management systems.
- CE Marking: Complies with European safety, health, and environmental requirements.
- IEEE Standards: Adheres to IEEE 1451 for transducer interface compatibility.
Benefits
- Predictive Maintenance: Identifies abnormal shaft movements before they escalate into equipment failures.
- Safety Enhancement: Reduces risks of catastrophic failures in high-speed rotating machinery.
- Operational Efficiency: Optimizes machinery performance by minimizing vibration-induced losses.
- Cost Savings: Extends equipment lifespan and reduces unplanned downtime through early fault detection.
- Centralized Monitoring: Integrates with Bently Nevada’s System 1 platform for enterprise-wide asset health management.
- Scalability: Supports multi-module configurations for large-scale industrial applications.
