Product Short Description
Technical Specifications
- Sensor Type: Eddy current proximity transducer.
- Measurement Range:
- Radial (shaft vibration/displacement): 0.25 mm to 12.7 mm (0.010 in to 0.500 in) peak-to-peak.
- Axial (thrust position): Up to ±6.35 mm (±0.250 in).
- Linearity: ±1% of full-scale output over the specified range.
- Sensitivity: 8 mV/μm (200 mV/mil) at standard operating conditions.
- Frequency Response: DC to 10 kHz (adjustable for specific applications).
- Output Signal: Voltage (±10 VDC max) compatible with monitoring systems and data acquisition devices.
- Operating Temperature:
- Sensor: -40°C to +125°C (-40°F to +257°F).
- Extension Cable: -40°C to +85°C (-40°F to +185°F).
- Proximitor® (signal conditioner): 0°C to +65°C (+32°F to +149°F).
Description
- Environmental Rating:
- Sensor: IP67 (dust-tight and protected against temporary immersion).
- Proximitor®: IP54 (protected against limited dust and water splashes).
- Target Material: Conductive metals (e.g., steel, stainless steel, aluminum).
- Cable Length: Standard 5 m (16.4 ft), extendable up to 9 m (29.5 ft) with compatible cables.
- Weight:
- Sensor: 0.1 kg (0.22 lbs).
- Proximitor®: 0.3 kg (0.66 lbs).
Key Features
- Non-Contact Measurement: Eliminates wear and tear associated with mechanical sensors.
- High Resolution: Detects micro-displacements (as low as 0.5 μm / 0.00002 in) for early fault detection.
- Real-Time Monitoring: Provides instantaneous feedback on shaft position and vibration.
- Rugged Design: Withstands harsh industrial environments, including high temperatures, vibration, and electromagnetic interference.
- Self-Diagnostic Capabilities: Monitors sensor health and alerts users to cable faults or calibration issues.
- Easy Installation: Pre-calibrated system with plug-and-play connectivity to monitoring platforms.
- Multi-Axis Compatibility: Supports radial (X/Y) and axial (Z) measurements for comprehensive machinery analysis.
Application Scenarios
- Turbomachinery: Monitoring rotor vibration and thrust position in gas turbines, steam turbines, and compressors.
- Power Generation: Detecting shaft misalignment in generators and hydroelectric turbines.
- Oil & Gas: Measuring vibration in centrifugal pumps, reciprocating compressors, and downhole drilling equipment.
- Aerospace: Testing engine components and rotor systems for vibration and balance.
- Industrial Manufacturing: Tracking spindle displacement in CNC machines and rolling mills.
- Marine Propulsion: Monitoring shaft alignment in propulsion systems for ships and submarines.
Industry Compliance
- API 670: Certified for machinery protection systems in critical rotating equipment.
- ATEX Zone 2/IECEx: Approved for use in hazardous environments (explosion-proof versions available).
- ISO 9001: Manufactured under strict quality management systems.
- CE Marking: Complies with European safety, health, and environmental requirements.
Benefits
- Predictive Maintenance: Identifies abnormal shaft movements before they lead to equipment failure.
- Safety Enhancement: Reduces risks of catastrophic failures in high-speed rotating machinery.
- Operational Efficiency: Optimizes machinery performance by minimizing vibration-induced losses.
- Cost Savings: Extends equipment lifespan and reduces unplanned downtime.
- Data Integration: Seamlessly connects with Bently Nevada’s System 1 platform for centralized asset health management.
