Product Short Description
Technical Specifications
- Sensor Type: Piezoelectric or strain-gauge pressure transducer (depending on configuration).
- Pressure Range:
- Standard: 0 to 10,000 psi (0 to 690 bar).
- Custom ranges available upon request.
- Accuracy: ±0.5% full scale (FS) over operating temperature range.
- Frequency Response: 0 Hz to 5 kHz (adjustable for specific applications).
- Output Signal: Voltage (typically ±5 VDC or ±10 VDC) or current (4-20 mA) proportional to pressure.
- Supply Voltage: 24 VDC ±10% (for voltage output) or 12-30 VDC (for current output).
- Operating Temperature: -40°C to +125°C (-40°F to +257°F).
- Storage Temperature: -55°C to +150°C (-67°F to +302°F).
- Enclosure Rating: IP67 (dust-tight and protected against temporary immersion).
- Process Connection: 1/4-18 NPT (male) or custom fittings for compatibility with industrial piping.
- Weight: Approximately 0.8 kg (1.8 lbs).
- Material: Stainless steel housing with hermetic sealing for corrosion resistance.
Description
Key Features
- High Dynamic Range: Captures rapid pressure fluctuations (e.g., pulsations in compressors) with minimal distortion.
- Rugged Design: Withstands shock, vibration, and extreme temperatures for reliable operation in harsh environments.
- Multi-Output Options: Supports voltage or current signals for compatibility with diverse monitoring systems.
- Built-In Signal Conditioning: Includes amplification and filtering to reduce noise and improve measurement accuracy.
- Diagnostic Capabilities: Monitors sensor health and alerts users to overpressure or calibration drift.
- Easy Calibration: Field-adjustable zero and span settings for quick recalibration.
Application Scenarios
- Oil & Gas: Monitoring pressure in reciprocating compressors, wellheads, and pipeline systems.
- Power Generation: Tracking steam and gas pressures in turbines and boiler feedwater systems.
- Aerospace: Engine testing and combustion chamber pressure analysis.
- Automotive: Measuring cylinder pressures in internal combustion engines and hydraulic systems.
- Chemical Processing: Monitoring reactor pressures and pump discharge conditions.
- Marine & Offshore: Pressure sensing in propulsion systems and offshore drilling equipment.
Industry Compliance
- API 670: Certified for machinery protection systems (when integrated with monitoring platforms).
- ATEX Zone 2/IECEx: Approved for use in hazardous environments.
- CSA Class I Division 2: Compliant with safety standards for explosive atmospheres.
- ISO 9001: Manufactured under quality management systems.
Benefits
- Predictive Maintenance: Detects abnormal pressure patterns to prevent equipment failures.
- Process Optimization: Enables real-time pressure control for improved efficiency.
- Safety Enhancement: Mitigates risks associated with overpressure events.
- Cost Reduction: Extends equipment lifespan by identifying issues before they escalate.
- Data Integration: Seamlessly connects with Bently Nevada’s System 1 platform for centralized asset health management.
